Digital Video CWDM SFP 3G Single SMD 10km Transceiver

Part Number: CWDM-SFP3G-10

3G-SDI CWDM SFP 10km SMF Single Transceiver

Digital Video CWDM SM SFP is a optical single mode transceiver module designed to transmit/receive optical serial digital signals as defined in SMPTE 297-2006. It supports from 50 Mbps to 3 Gbps and is specifically designed for transmitted the SMPTE 259M, SMPTE 344M, SMPTE 292M and SMPTE 424M SDI pathological patterns. It is with the SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of CWDM wavelength. There are eighteen center wavelengths available from 1270 nm to 1610 nm, with each step 20 nm

Key Features

• Speed from 50 Mbps to 3Gbps with up to 10 km Single-mode Fiber
• Single CWDM Trnasmitter: 1270 nm
• Single Receiver with Simplex LC
• Power Budger >15dB
• Digital Diagnostics Monitoring:With DDM
• Single +3.3 V Power Supply
• Based on Industry Standard SFP
• Support Video Pathological Patterns for SD-SDI, HD-SDI and 3G-SDI
• TTL Laser Disable Input
• TTL TX_Fault Output
• TTL RX_LOS Output
• Hot Pluggable
• SMPTE 297-2006 Compatible
• 0 to 70℃ Operation
• Class 1 Laser International Safety Standard IEC-60825 Compliant
• RoHS-6 Compliant
• same pin assignment as SFP MSA

OEM and ODM

F-tone designs, develops, manufactures and markets a diverse portfolio of high-performance, cost-competitive fiber optic communication products for all applications. We are mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply Digital Video SM SFP according to your requirements, and design Digital Video SM SFP label and packaging for your company.We welcome any inquiry for customized Digital Video SM SFP optical transceiver.
  Order Procedure
  Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
  a. Email ([email protected]) or Call (+86-027-8720-80-18) us a rough sketch to a detailed drawing.
  b. Our engineer will review the project and provide a quotation within 24 hours.
  c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Labeling

• F-tone Labels as default
• Generic Labels
• Specific Labels as Request
• No Labels

Packaging

• antistatic bag
• packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

Shipment

• International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
  FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
  DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
• Shipments are usually dispatched within 2 working days after received payment

Save Cost By Buying Digital Video SM SFP From Original Manufacturer F-tone Directly

F-tone offer customers a wide variety of 10 Gigabit Ethernet connectivity options Digital Video SM SFP for data center, enterprise wiring closet, and service provider transport applications. which is an professional manufacturer & supplier of Digital Video SM SFP transceivers. All of our Digital Video SM SFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee Digital Video SM SFP transceivers to work in your system and all of our Digital Video SM SFP come with a lifetime advance replacement warranty.
If you have questions about Digital Video SM SFP optics, please feel free to contact us at [email protected].

Applications

• SMPTE 297-2006 Compliant Electrical-to-Optical Interfaces
• High-density Video Routers

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
