10G DWDM C-band Tunable SFP+ 50GHz 80km DOM Transceiver Module Cisco DWDM-SFP10G-C

10G DWDM C-band Tunable SFP+ 50GHz 80km DOM Transceiver Module Cisco DWDM-SFP10G-C

Просмотреть всю информацию

Part Number: DWDM-SFP10G-C

Cisco Compatible 10G DWDM C-band Tunable SFP+ 50GHz Transceiver Module (SMF, 1563.86nm-1528.77nm, 80km, LC, DOM)

Product Details

Cisco Compatible DWDM-SFP10G-C Vendor Name F-tone
Form Type SFP+ Max Data Rate 10.3125Gbps
Channels C17-C61, total 89 Max Cable Distance 80km
Interface LC duplex Optical Components EML DWDM
Cable Type SMF DOM Support Yes
TX Power -1~3dBm Receiver Sensitivity <-22dBm
Commercial Temperature Range 0 to 70°C (32 to 158°F) Protocols MSA Compliant

Datasheet

Part Number Distance Wavelength Port
DWDM-SFP10G-40FM 40km C17~C61 LC
DWDM-SFP10G-80FM 80km C17~C61 LC

Quality Certification

Quality and standards are the foundation of F-tone. We are dedicated to providing customers with outstanding, standards-compliant products and services. F-tone has passed many quality system verifications, like CE, RoHS, FCC, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service.
Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.

Lifetime Warranty

All the fiber optic products in F-tone are fully warranted against defects in material and workmanship with a lifetime guarantee. This warranty does not cover damage caused by accident, improper care, improper use, negligence, normal wear and tear, or the natural breakdown of colors and materials over extended time and use.

Quality Control System:

Spectral Attenuation Measurement

WDM systems are divided into different wavelength patterns, conventional/coarse (CWDM) and dense (DWDM). Conventional WDM systems provide up to 8 channels in the 3rd transmission window (C-Band) of silica fibers around 1550nm. Dense wavelength division multiplexing (DWDM) uses the same transmission window but with denser channel spacing. Channel plans vary, but a typical system would use 40 channels at 100 GHz spacing or 80 channels with 50 GHz spacing. Dense wavelength division multiplexing (DWDM) refers originally to optical signals multiplexed within the 1550nm band so as to leverage the capabilities (and cost) of erbium doped fiber amplifiers (EDFAs), which are effective for wavelengths between approximately 1525-C1565nm (C band), or 1570-C1610nm (L band).


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

Посмотреть все

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

Посмотреть все

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
