F-tone S0313-2 - 125Mbps Fast Ethernet, 155Mbps OC-3/STM-1 SDH/SONET 1310nm Multi-mode Dual LC 2km SFP Transceiver Module

F-tone S0313-2 - 125Mbps Fast Ethernet, 155Mbps OC-3/STM-1 SDH/SONET 1310nm Multi-mode Dual LC 2km SFP Transceiver Module

Просмотреть всю информацию

Description

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • 1310 nm Transmitter,multi-mode fiber
  • 0 to 2000 m Transmission
  • AC/AC Coupling according to MSA
  • LV-TTL TX Disable Input Signal
  • LV-TTL RX Loss of Signal Output
  • Single +3.3 V Power Supply
  • RoHS Compliant

Specifications

Parameter Value
Part Number F-tone S0313-2
Device Type FE/OC3 SFP
Package SFP
Data Rate 155/125Mbps
Wavelength 1310nm
Distance/Power Budget 2km
Optical Components
  • LD: FP
  • PD: PIN
Output Power -19~-14dBm
Receiver Sensitivity -32dBm
Power Supply Voltage 3.3V
Connector Dual LC
Fiber Type MMF
Operating Temperature 0~70/ -10~80/ -40~85 °C
DDMI With/ Without
Application FE/ SDH/ SONET/ FTTx
Compatiblity All Brands

F-tone is the original manufacturer of FE/OC3 SFP F-tone S0313-2 - 125Mbps Fast Ethernet, 155Mbps OC-3/STM-1 SDH/SONET 1310nm Multi-mode Dual LC 2km SFP Transceiver Module. We have ready stock for F-tone S0313-2 and can ship it out in two business days. We guarantee the F-tone S0313-2 transceiver module to work in your system and all of our F-tone S0313-2 transceiver modules come with a lifetime warranty.

The F-tone S0313-2 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The F-tone S0313-2 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
