1U High 19' Fiber Patch Panel, 96 Fibers, 24 Ports LC Quad 9/125 Single Mode Fiber Adapters

1U High 19' Fiber Patch Panel, 96 Fibers, 24 Ports LC Quad 9/125 Single Mode Fiber Adapters

Просмотреть всю информацию

Part Number: FT-FPP1U24LCQSMF

96 Fibers, 24 Ports LC Quad 9/125 Singlemode Fiber Adapters, 1U High 19" Fiber Patch Panel

Fiber adapter panel served as the connector of fiber optic patch cables and enclosures allows for high density rack mount enclosures installation and provide a complete system solution for connectivity. It can applied to ODF, optical fiber communication equipment, FTTP, testing equipment etc.

No.of Adapter/Port 24 Fiber Count 96
Adapter Type SMF LC Quad Dimensions (LxW) 19''x1.73'' (482.6x44mm)
Plate C.R.S POWDER COATED Sleeve Material Ceramics
RoHS Compliancy Status Compliant Application Mount In A 19" Network Rack

Product Highlights

High Density Assemble Mounting - FHD Fiber Adapter Panel

Used with fiber cables, the panel provides interconnect or cross-connect capability at telecommunication rooms or work areas

A Rugged and Cost-Effective Designed FHD Series Fiber Adapter Panel

1. Compact High Density Design

Optimized space utilization, suitable for 1U 19" frame rack mount or cabinet in ODF, etc.

2.Metal Shrapnel Style Fixed Adapter

Metal shrapnel designed for the adapter more firmly fixed on the panel and avoiding the adapter fall off.

3.Endurance White Silk-Screen Labels

Printed by wear-resistant ink holds up very well to moisture and scuffing, fast and easy identification.

4.A Kraft Paper Material Packaging

The kraft paper material is characterized by high crush resistance and environment friendly. Dimension of box is 1.66*0.18*0.13(ft)

High Density Cable Management - 1U High 19" Fiber Patch Panel

1U horizontal cable management panel with rings are included to provide organized management of patch cables

Related Products

  • 1U Detachable Horizontal Cable Management Panel with D-ring & Lacing Bar
  • 3M LC UPC to LC UPC Duplex 3.0mm LSZH 9/125 Single Mode HD Fiber Patch Cable
  • 25m/Roll 1000in.L x 0.48in.W Back to Back Magnetic Velcro Cable Tie

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
