Opto-Mechanical Optical Switches 1RU 19' Rackmount

Part Number: FT-OSW-1xN-1U

Optical Switch Opto-Mechanical 1RU 19" Rackmount

1RU 19” Rackmount with no preinstalled optical switch modules. It is designed for 1xN (N≤16) opto-mechanical optical switch modules. Modules can be easily installed into the chassis. The dimension of this 1RU 19” rackmount chassis is 440X250X43mm.

The front panel bulkheads can be fit with typical FC/UPC, FC/APC, SC/UPC, SC/APC, LC/UPC, LC/APC, ST/UPC, ST/APC connector types. Normally the 1RU 19” rackmount can accept at most two 1x16 LC connector optical switch modules or one 1x16 FC/SC/ST connector optical switch modules, such as OSM-1x16.

F-tone provides comprehensive rackmounts, including 1RU rackmount, 2RU rackmount, 4RU rackmount, and Desktop rackmount, which can accept our 128-channel opto-mechanical optical switch modules. Our optical switch rackmounts are manufactured to the highest quality standards in state of art facilities. We also offer opto-mechanical optical switch modules to make a full set sollution.

Mechanical dimension

Key Features

• 1RU 19” rackmount standard chassis
• Compact, space-saving rackmount
• Dimension (LxWxD): 440X250X43mm (1U height)
• Capacity: 1x16 FC/SC/ST connector module up to 1pc or 1x16 LC connector module up to 2 pcs
• Easy for installation and maintenance
• Robust & rugged construction
• Ideal for our Opto-Mechanical Fiber Optical Switch Modules
• TTL & RS232 interfaces are available

Applications

• Flexible and versatile platform for packaging modules
• Secure modules
• Fiber-optical lab use
• R&D applications
• System compliance testing
• Metropolitan area network

Ordering Information

Notes

• N means channel number of optical switch modules. You can choose a optical switch module to match the chassis you choose.
• More than 128 channel module can be customized.
• Special size rack mount can be customized.

Custom Order Procedure

Please contact us with any specific requirements you may have, we can help you create a custom solution to meet almost any application.
a. Email [email protected]. your requirements, including a rough sketch and some detailed drawing and information.
b. Our engineer will review the project and provide a quotation within 2 to 3 business days.
c. We can arrange production in 2 to 3 weeks once an order is placed.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
