Semiconductor Optical Amplifier Butterfly package 1550nm 23dB Gain

Semiconductor Optical Amplifier Butterfly package 1550nm 23dB Gain

Просмотреть всю информацию

Part Number: FT-SOABF-15-G23

Semiconductor Optical Amplifier Switch with butterfly package MSOA-1550-Switch

Description

The semiconductor optical amplifier switch, MSOA-1550-Switch, addresses new areas in the optical switch market. The technology is based on well‐known semiconductor laser technology and packaging techniques, and offers a low‐cost alternative to conventional fiber switch solutions. SOA can operate at any wavelength from 1520-1650nm window and it is very suitable for optical blocking shutter or modulation with 65dB extinction ratio.


The devices are packaged in a butterfly package providing high coupling efficiency, low polarization sensitivity, and high saturation output power. MSOA-1550-Switch can be used to extend telecommunication or ns speed optical switch links by providing 18 ‐25 dB gain, < 2.0 dB polarization sensitivity, and 10dBm saturation power. Switch of both continuous wave (CW) signals and modulated signals is possible.

Features

  • 40G and 100G C‐Band blocking shutter or modulation
  • 14‐Pin MSA package
  • Low Noise Figure & Low polarization dependence
  • >1m SMF-28 250µm fiber with FC/APC connector

Specification

Parameter Symbol Min Typ Max Unit Note
Case Operating Temperature Range Tcase -15 65 ºC T=25 ºC, IF=300mA
Storage Temperature Tstore -40 85
Forward Current IF 300 350 mA
Reverse Voltage VREV 2 V
Fiber pigtail bending radius R 35 mm
Tensile strength fiber to case F 5 N
Gain bandwidth BW 50 nm
Gain Peak Wavelength lpeak 1535 nm
Peak Gain Gpk 23 dB
Max Input power Pmax 17 dBm
Gain Ripple ΔG 0.5 1 dB
3dB saturation output power P3dB 10 dBm
Polarization dependent gain PDG 1.5 2 dB
Optical noise figure NF 9 10 dB
Extinction Ratio On/FF ER 65 dB
Amplifiering Speed SS 1 ns
Forward Voltage VF 2.5 V
Thermistor resistance R 9.5 10 10.5 kW
Cooler current Icool 1.1 1.5 A
Cooler voltage Vcool 3.0 3.7 V

Dimensions and PIN


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
