1x8 Polarization Maintaining PM630 Fiber Optical Switch

1x8 Polarization Maintaining PM630 Fiber Optical Switch

Просмотреть всю информацию

Part Number: OSW-1x8-PM630-X

PM630 Optical Switch 1x8 Polarization Maintaining PM Fiber Optical Switch 630nm 5V Non-Latching 900um Pigtailed with USB Port Control

F-tone Polarization Maintaining Optical Switch (PM Fiber Switch) is a passive component possessing two or more ports that selectively transmits, redirects or blocks optical signals from a given input port to a given output port in an optical fiber transmission line. F-tone’s polarization maintaining (PM) fiber switches are fabricated from PM panda fibers and high-quality connectors that are compatible with industry standards. They are able to maintain a well-defined state of polarization (SOP) of the light. PM Fiber Switch 1x8 PM630 Optical Switch.

Features

◆Low Insertion Loss

◆ Wide Wavelength Range

◆ Low Crosstalk

◆High Stability, High Reliability

◆ Epoxy-free on Optical Path

◆ Latching and Non-latching

Application

●Metropolitan Area Network

●R&D in Laboratory

●System Monitoring

●Configurable OADM

◇ Dimension

Type A(N ≤ 32)

Type B(N ≤ 64)

Optical Route:

Flexible Architectures

◇ Performance

Parameters PMOSW-1X8
Fiber type nm PM630,PM780 PM 1310,PM1550
Testing Wavelength nm 630, 780 1310,1550
Insertion Loss dB Typ:1.0,Max:1.3 Typ:1.0 ,Max:1.2
Return Loss dB ≥30 ≥50
Crosstalk dB ≥35 ≥50
ER dB 18.00
WDL dB ≤0.25
TDL dB ≤0.25
Repeatability dB ≤±0.02
Power supply v 3.0 or 5.0
Lifetime Cycle ≥107
Switch Time ms ≤8
Transmission Power mW ≤500
Operation Temperature ℃ -40~+85
Storage Temperature ℃ -40~+85
Weight g 16
Dimension mm (L)33×(W)26×(H)8.5(±0.2)

◇ Pins

Latching Relay1 Relay2 Relay1 Relay2
Pin1 Pin5 Pin6 Pin10 Pin1 Pin5 Pin6 Pin10 2-3,8-9 3-4,7-8 2-3,8-9 3-4,7-8
Port0-Port1 V+ GND -- -- -- -- GND V+ Open Close Close Open
Port0-Port2 V+ GND -- -- V+ GND -- -- Open Close Open Close
Port0-Port3 -- -- GND V+ V+ GND -- -- Close Open Open Close
Port0-Port4 -- -- GND V+ -- -- GND V+ Close Open Close Open

NON-Latching Relay1 Relay2 Relay1 Relay2
Pin1 Pin5 Pin6 Pin10 Pin1 Pin5 Pin6 Pin10 2-3,8-9 3-4,7-8 2-3,8-9 3-4,7-8
Port0-Port1 V+ -- -- GND -- -- -- -- Open Close Close Open
Port0-Port2 V+ -- -- GND V+ -- -- GND Open Close Open Close
Port0-Port3 -- -- -- -- V+ -- -- GND Close Open Open Close
Port0-Port4 -- -- -- -- -- -- -- -- Close Open Close Open

◇ Ordering Information：PMOSW－1X8－A － B－C－D－E－F－G

A B C D E F G
Fiber Mode Wavelength Voltage Control Model Fiber Diameter Fiber Length Connector
P63:PM630 63: 630nm

85: 850nm

13: 1310nm

14: 1490nm

15: 1550nm

162: 1625nm

165: 1650nm

13/15:1310/1550nm		 3: 3V

5: 5V		 L: Latching

N:Non-Latching		 25:250um

90:900um		 05:0.5m

10:1.0m

15:1.5m		 OO: None

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

LP: LC/PC

LA: LC/APC



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
