AR-Coated PM Patch Cables FC UPC to FC UPC PM PANDA for 1440-1620nm 2m

AR-Coated PM Patch Cables FC UPC to FC UPC PM PANDA for 1440-1620nm 2m

Просмотреть всю информацию

Part Number: PC-1550PMAR-2

AR-Coated PM Patch Cables FC UPC to FC UPC PM PANDA for 1440-1620nm 2m length

Fiber
Type		 Bare Fiber
Wavelength Range		 Cutoff
Wavelength		 MFDb Min Extinction
Ratioc 		Max Insertion
Lossc 		Max
Attenationd 		NA Length Jacket
PM1550-XP 1440-1625 nm 1380 ± 60 nm 10.1 ± 0.4 µm
@ 1550 nm		 23 dB 0.5 dB <1.0 dB/km
@ 1550 nm		 0.125 2 m FT030-BLUE
(Ø3 mm)
  • The shaded region represents the specified wavelength range of the AR coating, which is different than the fiber's operating wavelength range, indicated in the graph title.
  • Mode Field Diameter
  • Specified at the Alignment Wavelength of 1550 nm
  • Specified for Unterminated Fiber

Item # AR-Coated Connector Uncoated Connector AR Coating AR Coating Reflectivitya
PC-1550PMAR-2 FC/PC FC/PC Ravg<0.5% for 1050 - 1620 nm
PC-1550PMAR-21 FC/PC FC/APC


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
