AR-Coated PM Patch Cables FC PC to FC PC for 620 - 800nm 2M

AR-Coated PM Patch Cables FC PC to FC PC for 620 - 800nm 2M

Просмотреть всю информацию

Part Number: PC-630PMAR-2

AR-Coated PM Patch Cables FC PC to FC PC for 620 - 800nm 2M length

Fiber
Type		 Bare Fiber
Wavelength Range		 Cutoff
Wavelength		 MFDb Min Extinction
Ratioc		 Max Insertion
Lossc		 Max
Attenuationd		 NA Length Jacket
PM630-HP 620-850 nm 570 ± 50 nm 4.5 ± 0.5 µm
@ 630 nm		 20 dB 1.2 dB <15 dB/km
@ 630 nm		 0.12 2 m FT030-BLUE
(Ø3 mm)
  • The shaded region represents the specified wavelength range of the AR coating, which is different than the fiber's operating wavelength range, indicated in the graph title.
  • Mode Field Diameter
  • Specified at the Alignment Wavelength of 630 nm
  • Specified for Unterminated Fiber
Item # AR-Coated Connector Uncoated Connector AR Coating AR Coating Reflectivitya
PC-630PMAR-2 FC/PC FC/PC Ravg<0.5% for 500 - 800 nm
PC-630PMAR-2 FC/PC FC/APC


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
