AR-Coated Multimode Fiber Patch Cable 650 - 1100nm SMA905 Connector

AR-Coated Multimode Fiber Patch Cable 650 - 1100nm SMA905 Connector

Просмотреть всю информацию

Part Number: PCAR-200L02SB

AR-Coated Multimode Fiber Patch Cable 650 - 1100nm SMA905 Connector 2M length

AR-Coated Multimode Patch Cables for 650 - 1100 nm (SMA905 Connectors)

Item # Fiber Type Core Cladding Operating
Wavelength
Rangea 		Fiber
Attenuation
(Click for Graph)		 NA AR Coating AR
Plot		 Length Bend Radius
Short Termb Long Term
50L02S-B FG050LGA Ø50 µm ± 2% Ø125 ±1 µm 650 - 1100 nm 0.22 Ravg < 0.75%
from 650 - 1100 nm		 2 +0.075/-0.0 m 23 mm 30 mm
105L02S-B FG105LCA Ø105 µm ± 2% Ø125 ±1 µm 650 - 1100 nm 23 mm 30 mm
200L02S-B FG200LCC Ø200 ± 8 µm Ø240 ± 5 µm 650 - 1100 nm 23 mm 24 mm
  • The operating wavelength range of the patch cable is determined by the wavelength range of both the bare fiber and AR coating.
  • Limited by the minimum bend radius of the outer FT05SS tubing.


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
