1x1 PM Optical Switch PM1550nm 5V Non-Latching 900um 1m

1x1 PM Optical Switch PM1550nm 5V Non-Latching 900um 1m

Просмотреть всю информацию

Part Number: PMOSW-1x1-X

1x1 Polarization Maintaining Optical Switch PM Switch 1550nm 5V Non-Latching 900um

F-tone Polarization Maintaining Optical Switch (PM Fiber Switches) is a passive component possessing two or more ports that selectively transmits, redirects or blocks optical signals from a given input port to a given output port in an optical fiber transmission line. F-tone’s polarization maintaining (PM) fiber switches are fabricated from PM panda fibers and high-quality connectors that are compatible with industry standards. They are able to maintain a well-defined state of polarization (SOP) of the light.

Features

◆Low Insertion Loss

◆ Wide Wavelength Range

◆ Low Crosstalk ◆High Stability, High Reliability

◆ Epoxy-free on Optical Path

◆ Latching and Non-latching

Application

●Metropolitan Area Network

●R&D in Laboratory

●System Monitoring

●Configurable OADM

Dimensions

Performance

Parameters PMOSW-1×1
Wavelength Range nm 650~1310 1260~1670
Testing Wavelength nm 650/780/850/980/1064/1310 1310/1490/1550/1625/1650
Insertion Loss dB Typ:0.6,Max:1.0 Typ:0.5 ,Max:0.8
Return Loss dB ≥35 ≥50
Crosstalk dB ≥40 ≥50
ER dB >18
PDL dB ≤0.05
WDL dB ≤0.25
TDL dB ≤0.25
Repeatability dB ≤±0.02
Power supply v 3.0 or 5.0
Lifetime Cycle ≥107
Switch Time ms ≤8
Transmission Power mW ≤500
Operation Temperature ℃ -40~+85
Storage Temperature ℃ -40~+85
Weight g 16
Dimension mm (L)27×(W)12.6×(H)8.5(±0.2)

Pins

Optical Path Electric Drive Sensor Status
1×1 1 5 6 10 3－4,7－8 2－3,8－9
Latching P1-/-P2 +5V GND N/A N/A CLOSE OPEN
P1---P2 N/A N/A GND +5V OPEN CLOSE
Non-

Latching		 P1-/-P2 N/A N/A N/A N/A CLOSE OPEN
P1---P2 N/A +5V GND N/A OPEN CLOSE

Electrical parameters

Voltage current Resistor
5V Latching 4.5~5.5 36~44mA 125Ω
5V Non-Latching 4.5~5.5 26~32mA 175Ω
3V Latching 2.7~3.3 54~66mA 50Ω
3V Non-Latching 2.7~3.3 39~47mA 70Ω

Ordering Information

PMOSW－1×1－A－B－C－D－E－F－G

A B C D E F G
Fiber Mode Wavelength Voltage Control Model Fiber Diameter Fiber Length Connector
P3:PM1300

P4:PM14XX

P5:PM1550		 85: 850nm

13: 1310nm

14: 1490nm

15: 1550nm

162: 1625nm

165: 1650nm

13/15:1310/1550nm		 3: 3V

5: 5V		 L: Latching

N:Non-Latching		 25:250um

90:900um		 05:0.5m

10:1.0m

15:1.5m		 OO: None

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

LP: LC/PC

LA: LC/APC



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
