POP-311 Handheld Fiber Polishing Machine for MT on-site Polishing

POP-311 Handheld Fiber Polishing Machine for MT on-site Polishing

Просмотреть всю информацию

Part Number: POP-311-NTT-AT-FM

Perfect for field or on-site! Compact handheld fiber optical connector polishing machine!

Fiber Optical connector installation work for detached houses and broadband compatible condominiums associated with FTTH. Excess length processing optical connector installation work associated with optical fiber laying in intelligent buildings, or regrinding of damage repair of already laid optical fiber connector end faces. These can be worked on site.
It can also be used as the world's first manual MT/MPO polishing machine by using the attachment for MT/MPO (sold separately).

Feature

battery powered

Easy-to-find rechargeable Ni-MH batteries (AA) and alkaline batteries (AA) can be used.
high speed polishing

Polishes optical connectors at a high speed rotation of 700 times per minute. Moreover, it can be easily done on site in 3-5 processes.
Adhesive removal ~ AdPC polishing ⇒ 150 seconds (SC connector/terminal)
AdPC polishing by regrinding ⇒ 50 seconds (SC connector/terminal)
(AdPC Polishing: Advanced PC Polishing)
high quality polishing

Generous use of technology cultivated in mass-production polishing machines at factories. Polishing quality is the same level as for factory use.

Specifications

Usage Optical connector polishing (for regrinding and new polishing processing)
Target connector
(ferrule)		 SC, MU, FC, LC, MT,
MTP/MPO ™, MTRJ type optical connector, glass ferrule and custom
Abrasive properties curvature radius 10-25mm
convex spherical eccentricity < 50μm
Fiber entry < 0.05 µm
return loss >50dB
Weight 830g (excluding batteries)
External dimensions 90W x 75D x 212H (mm)


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
