S0315-120 - 125Mbps FE/OC3 SFP 1550nm 120km LC SMF

S0315-120 - 125Mbps FE/OC3 SFP 1550nm 120km LC SMF

Просмотреть всю информацию

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • Compliant with SONET OC-3 /SDH STM-1
  • 1550 nm DFB LD Transmitter
  • 34 dB Power Budget at Least
  • Distance up to 120 km
  • Single +3.3 V Power Supply
  • RoHS Compliant

Specifications

Parameter Value
Part Number S0315-120
Data Rate 155/125Mbps
Wavelength 1550nm
Distance 120km
Output Power 0~5dBm
Receiver Sensitivity -35dBm
Fiber Type SMF

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract.
