S0385-05 - 125Mbps FE/OC3 SFP 850nm 550m LC MMF SX

S0385-05 - 125Mbps FE/OC3 SFP 850nm 550m LC MMF SX

Просмотреть всю информацию

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • 850 nm(VCSEL) transmitter
  • 300 m links with 62.5/125 mm MMF Cables
  • 500 m links with 50/125 mm MMF Cables
  • AC/AC Coupling according to MSA
  • Single +3.3 V Power Supply
  • RoHS Compliant

Specifications

Parameter Value
Part Number S0385-05
Device Type SFP SX
Package SFP
Data Rate 125Mbps/155Mbps
Wavelength 850nm
Distance 550m
Optical Components LD: VCSEL, PD: PIN
Output Power -9~-4dBm
Receiver Sensitivity -17dBm
Power Supply 3.3V
Connector Dual LC
Fiber Type MMF
Operating Temperature 0~70°C
Application Ethernet/FC

Description

F-tone Networks is the original manufacturer of SFP SX S0385-05 - 125Mbps Fast Ethernet, 155Mbps OC-3/STM-1 SDH/SONET 850nm Multi-mode Dual LC 550m SFP Transceiver Module.

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract.
