Extreme 10309 Compatible 10GBASE-ER SFP+ 1550nm 40km Transceiver

Part Number: SFP-10G55-40A-E

10GBASE-ER SFP+ 1550nm 40km Transceiver Extreme 10309 Compatible

The SFP-10G55-40A series single mode transceiver is small form factor pluggable module for duplex optical data communications up to 10G such as IEEE 802.3ae 10GBASE-ER. This transceiver offers the same function with Extreme 10309 and it is fully compatible with Extreme devices.It is with the SFP+ 20-pin connector to allow hot plug capability.This module is designed for single mode fiber and operates at a nominal wavelength of 1550 nm. The transmitter section uses a 1550nm EML, which is class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

Key Features

• 1550nm EML Transmitter
• Distance up to 40km over SMF
• Average Output Power:-4.7~4dBm
• Receiver Sensitivity:-15.8dBm
• Single 3.3V Power supply and TTL Logic Interface
• Duplex LC Connector Interface, Hot Pluggable
• Power Dissipation < 1.5 W (Typical < 1W)
• Dispersion Tolerance 800ps/nm
• Compliant with SFF-8431 MSA
• Compliant with SFF-8432 MSA
• Compliant with SFF-8472 MSA
• Built-in Digital Diagnostic Function
• Operating Case Temperature Standard : 0°C to +70°C

Applications

• 10GBASE-ER/EW
• 8G/10G FC
• Other Optical Link

Ordering Information

Notes
F-tone also provide other 10G SFP+ transceivers with different transmission distances, like100km

Packaging

• Antistatic bag
• Packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply SFP-10G55-40A according to your requirements, and design SFP-10G55-40A label and packaging for your company.We welcome any inquiry for customized SFP+ optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying 10G SFP+ From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of 10G SFP+ transceivers. All of our 10G SFP+ transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee 10G SFP+ transceivers to work in your system and all of our 10G SFP+ transceivers come with a lifetime advance replacement warranty. If you have questions about 10G SFP+ optics, please feel free to contact us at [email protected].

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
