Single Port SFP Gigabit Ethernet Server Adapter

Single Port SFP Gigabit Ethernet Server Adapter

Просмотреть всю информацию

Part Number: NIC-1G-1F
Product Name: SFP Transceiver Single Port  PCI-E Gigabit Lan Card
Brand: F-tone

Product Description
NIC-1G-1F Single Port PCIe Gigabit Lan Card is based on Intel original controller chip INTEL82572EI, PCI Express bus, SFP slot and LC cable fiber connectivity, to achieve professional Gigabit Ethernet network connectivity.

Applications
This Single Port PCIe gigabit Lan Card is mainly used in all kind of servers and workstations.

Main Features

  • Build on PCI Express Technology and Intel original Gigabit controller technology.
  • Based on Gigabit SFP transceivers which are optional and replaceable.
  • High-performance gigabit SFP Transceivers (1000BASE-SX, 1000BASE-ZX) connections for slot-constrained servers.
  • Gigabit scalability and increased uptime through advanced server features.


Specifications

  • Intel 82572EI Chipset Controller
  • PCI Express 2.0a Bus type
  • PCIe x4, x8, x16 lane Bus Width
  • Single Port, SFP*1 Slot
  • Support 10, 100, and 1000 Mbps Speed Rate
  • SFP Transceiver *1, (1000BASE-SX, 1000BASE-LX, 1000BASE-ZX). LC fiber optical cables, you can choose (SM-10KM/20KM/40KM/60KM/80KM Or MM-550M) which you wanted.
  • IEEE 802.3(1000BASE-SX, 1000BASE-LX, 1000BASE-ZX) Network standard
  • 1 (color) solid and blinking LED
  • Includes a full-height bracket and a low profile bracket.
  • Physical Dimensions(Length* Width):13.7cm*6.8cm


NOS Software Support

  • Microsoft Windows* Server 2003, Enterprise, Datacenter (32- and 64-bit)
  • Microsoft Windows 2000
  • Red Hat Linux* 2.4x or later (32- and 64-bit)
  • FreeBSD 4.x or later
  • Novell Netware* 5.x, 6.x
  • Sun Solaris* x86, OS 8 and later
  • SCO Open Server 5, Open Unix 8*

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
