Eleven-in-One CCTV Security Camera Tester with 3.5 inch LCD Monitor STest-895

Part Number: STest-895

Eleven-in-One CCTV Security Camera Tester with 3.5 inch LCD Monitor STest-895

Introduction

The CCTV tester PRO STest-895 combine the video test, Optical Power Meter, Digital Multi-meter, PTZ controller, video signal level test, NTSC/PAL color pattern generator, UTP cable test, PTZ protocol analysis, PTZ address scan, DC12 1A output, Audio test to one body.
It is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.
STest-895 equipped with the Optical Power Meter. Use in testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.
STest-895 is an ideal multifunction Instrument for CCTV security system, Fiber Optical communication, CATV and other Fiber Optic works.

Features

• 3.5"TFT-LC, 960(H) ×240 (V) resolution
• Optical power meter, testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord, etc.
• Digital Multimeter, performs AD/DC Voltage, AC/DC Current, Resistor, Conductivity, Capacitor and Diode test.
• DC12V power output
• Audio input
• Adjustable brightness, contrast, color of LCD
• Video Level testing, video signals measured in IRE or mV
• Automatically identify and adapt the video mode of NTSC and PAL
• Colorbar Video signal generator, transmit/receive colorful images
• Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc
• PPTZ address scanning, search up the ID of PTZ camera
• Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment
• Support RS232 and RS485 interface, the rate 150-19200bps
• Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
• PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset
• Lithium Ion Polymer Batteries(3.7V DC3000mAh), more reliable, and work 15 hours
• Easy for use that the train is almost unnecessary

Application

CCTV system installation and maintenance
Dome camera and All in one camera testing
The CCTV transmitting channel testing
PTZ controller

Family Comparison

Specification

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
