MPO Fiber Interferometer for multi-channel mpo connector fiber endface 3d testing 0.5s auto focus

Part Number: SUN-Mars-FIMPO

MPO Fiber Interferometer SunmaFiber-MT

SunmaFiber-MT Fiber Connector Optical Interferometer is a high precision instrument developed and manufactured by Chengdu Sunma Technology Co., Ltd. to measure the end face geometry of optical fiber connectors. It can supply the 3D topology image combining the newest high-speed computer and powerful software system.

Information:

SunmaFiber-MT interferometer use white light and red light combined with the measurement of multi-fiber connector, the use of red light to measure single fiber connectors. Single and multi fiber measurement use the same software design, a key switching. The process of focusing, calibration, and measurement is completed automatically by software. SunmaFiber-MT single - and multi - fiber interferometer is mainly divided into two parts, the host computer and the special measuring software. The equipment is mainly composed of the following characteristics:

Up to 72 cores test and quick speed, customized clamp


(2)Simple and user friendly software interface

Key Features and Benefits:

1. No-contact white light and fast response of measurement.
2. Precise data processing, with high accuracy measurement results.
3. Novel robust algorithm, accurate results even with contaminated ferrule surface
4. High-precision and long life fiber clamp.
5. Automatically generate three-dimensional map, fitting map which directly reflect the details of the optical fiber connector;
6. Automatically generate test reports and test data in Excel format, which is easy to manage and print;

Specification:

Multi-Fiber Measure Item Measurement Range Repeatability Reproducibility
X/Y Ferrule Radius（mm） 3~∞ 1% 3%
X/Y Ferrule Angle（°） 0 or 8 0.01 0.02
Fiber Height（um） 0~8 0.015 0.025
Test Speed(Second) MT-12 5s（Without Auto Focusing）
Single-Fiber Radius Of （mm） 3~∞ 0.1% 0.2%
Fiber Height（nm） -150~+150 1 2
Appex offset（um） 0~500 1.0 1.5
APC Angle（°） 0 or 8 0.01 0.015
Test Speed(Second) 0.5s
Objective Zoom Time 2X
Resolution Ratio 2.6um
Light Source Red and White
Power Supply 220V 50Hz

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
