Polarization Maintaining Fiber Axis Rotation Alignment System for PM Fiber Axis Alignment Automatic Type

Polarization Maintaining Fiber Axis Rotation Alignment System for PM Fiber Axis Alignment Automatic Type

Просмотреть всю информацию

Part Number: SUNMA-PMRA-X

Automatic Polarization Maintaining Rotation Alignment System for PM Fiber Axis Alignment, PM Optical Align system of Slow Axis and Fast Axis, Polarization Maintaining Fiber Align System & optical waveguide alignment and packaging

Low-cost, Compact, High Precision and Maneuverable Auto-Alignment Machine for PM Fiber Axis Rotation Alignment, used for PM fiber patchcord Manufacuring and Alignment of Polarization Maintaining Fiber Components and PM Fiber Optics

The Sunma instrument company develops a new generation of manual and auto aligner for PM fiber axis alignment. This product line features cost effective, high precision motion control capability with a compact mechanical design. Optical Waveguide Alignment Machine
High quality components are used to assemble the system to guarantee high precision and repetitive motion applications.OEM customized manual, semi-auto and fully automatic system according to customer’s applications.
We provide 2-day Free training, Installation& Calibration, all for Free.

Features:

  • High Stability Stainless Steel Ultra-Precision linear stage
  • High Repeatability Stainless Steel fixtures and jigs
  • High resolution motion platform and micrometer for high precision and repeatability waveguide alignment
  • Compact and highly maneuverable design
  • Modular design, seamless upgrade to piezo-electric and motor-driven semi-auto alignment system

Applications:

  • Silicon Polarization Maintaining Fiber roation waveguide alignment/coupling
  • Polarization Maintaining Fiber Slow Axis alignment
  • Polarization Maintaining Fiber Fast Axis alignment
  • PM Circulator, Arrayed waveguide grating
  • PM Collimator, PM Patch Cables, PM Fiber switches
  • Special/customized PM fiber and other related PM optical waveguide alignment

System confguration:

Specifications:

Translation（X-Y-Z axis）
Component Sunma 562 ULTRAlignTM Precision Multi-Axis Positioning System
Travel Range（mm） XYZ: 13mm (X, Z optional 25mm)
Actuator Resolution（μm） SM-13 (0.5); DM-13 (0.05)
Load Capacity（N） 156
Materials All Stainless Steel
Rotation（PitchθX-YawθY-RollθZaxis）
Component NP-YP1 (Pitch-Yaw); NP-R1 (Roll)
Travel Range（mm） θX:6mm, θY:6mm, θZ:12mm (±3°)
Resolution（μm） NP-YP1 (0.01°), NP-R1 (0.0004°)
Materials Stainless Steel/Aluminium
Tooling
（Patent Pending）Universal Fiber Array Holder × 2
（Patent Pending）Universal 1×N Splitter Holder（1×2 to 1×64）× 1
Vision
Camera Type CCD×1
Lighting LED Bar Light（Top view、Side view）
Motion 100mm（according to request）
6 or 13mm manual XY stage



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
