10G DWDM C-band Tunable XFP 40km Transceiver

Part Number: TDWDM-XFP10G-40

10G DWDM XFP Tunable C-band 40km SMF Transceiver

F-tone TDWDM-XFP10G-40 series optical transceiver is a unique product which enables you to set the channel or “color” that the laser emits. Tunable transceivers are typically used as “spare-optics”, in case of emergency, because you can tune them to the right channel and reduce the amount of spare optics you need to hold in stock. Typically these tunable optics are for the C-Band 50GHz. Around 88 different channels can be set with intervals of 0.4nm, which is the 50GHz band. The TDWDM-XFP10G-40 complies with the 10 Gigabit small form factor pluggable (XFP) multisource agreement (MSA).
It complies with the ITU-T G.698.1 S-D100S1-2D standard with 50GHz channel spacing for SONET/SDH, IEEE DWDM 10GBASE-ER for 40 km reach (Ethernet), and DWDM 10GFC for 40 km reach (Fibre Channel) applications. This transceiver contains both transmit and receive sections. On the transmit side, the 10 Gbps serial data stream is recovered, retimed, and passed to a modulator driver.
The modulator driver biases and modulates a C-band-tunable integrated laser, enabling data transmission over single-mode fiber through an industry-standard LC connector. On the receive side, the 10Gbps optical data stream is recovered from an APD/transimpedance amplifier, retimed, and passed to an output driver. This module features a hot-pluggable XFI-compliant electrical interface.

Key Features

• Supports 9.953 Gbps (SONET and SDH), 10.31 Gbps (Ethernet), 10.52 Gbps (Fibre Channel), and corresponding Forward Error Correction (FEC) rates of 10.66/10.709/11.09/11.35 Gbps
• C3.Monolithically integrated full C-band tunable transmitter
• 50 GHz ITU channel spacing with integrated wavelength locker
• 40km MZM Tunable TOSA
• Hot-pluggable XFP footprint
• Maximum power dissipation of 3.5 W
• Commercial operating temperature from -5°C to 70°C
• Digital diagnostic monitoring support
• Telcordia GR-253-CORE and tested in accordance with GR-468
• ITU-T G.691
• IEEE 802-3ae-2002
• 10 GFC 1200-SM-LL-L

Applications

• DWDM 10Gb/s SONET/SDH
• DWDM 10Gb/s SONET/SDH with FEC
• SONET OC-192 and SDH STM-64
• DWDM 10Gb/s Ethernet & 10Gb/s
• Fiber Channel with FEC

Ordering Information

Notes

• XXX means DWDM ITU Channel (CH17 = 1563.86nm, CH18 =1563.05nm, CH19 = 1562.23nm, CH20 = 1561.42nm, etc.)

Packaging

• Antistatic bag
• Packed on pallets in a box(Default Customer Options)
• Specific Labels as Request
• Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

• OEM/ODM order is available
• We can supply TDWDM-XFP10G-40 according to your requirements, and design TDWDM-XFP10G-40 label and packaging for your company. We welcome any inquiry for customized 10G DWDM XFP optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying 10G Tunable DWDM XFP From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of Tunable DWDM XFP transceivers. All of our Tunable DWDM XFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee Tunable DWDM XFP transceivers to work in your system and all of our Tunable DWDM XFP transceivers come with a lifetime advance replacement warranty. If you have questions about Tunable DWDM XFP optics, please feel free to contact us at [email protected].

All the 10GB Tunable DWDM XFP 80km 50GHz Wavelength that we can offer refer to the following table:

Prices and specifications are subject to change without notice. F-tone.Com Transceiver is not responsible for typographical or photographic errors.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
