4 Fibers Single-mode Armored Field Tactical Fiber Optic Cable

4 Fibers Single-mode Armored Field Tactical Fiber Optic Cable

Просмотреть всю информацию

Part Number: WTF-4B1.1

Single-mode Single Armor 4 Fibers Field Tactical Fiber Optic Cable

Single-armored tactical optical cable with the characteristics of strong tension stress, strong compressive resistance, high flexibility, bending resistance, used for military tactical field, communication between radars or oil field, mining work place.

It has the compact all dielectric structure, for easy installation and repeatable usage. SUS spring tube combined with the braiding to strength the cable, and ensures high mechanical and transmission performance. Flame retardant PU guarantees structure stability and features of crush-resistant, rubbing-resistant, oil-resistant and flame retardant.

Item Details

  • Fiber Count: 4 Fibers
  • Fiber Type: Single-mode G.652B

Cable Structure

Features
  • High intensity optical fiber coating with compound structure guarantees cable's stability and durability.
  • The PU jacket is flame retardant.
  • Kevlar make cable have excellent tensile strength.
  • All all dielectric structure, light weight.
  • Good mechanical and environmental characteristics.
Application
  • Military communication system
  • Communication between radars or oil field,mining work place
  • Excellent for use in deployment/retrieval applications

Package

Package 1
Package 2
Package 1: usually for indoor cable, light weight cables.
Package 2: usually for outdoor cable, heavy weight cables
Usually for each roll, the cable length is 2km, but we could provide customized package for different cable lengths.

Mark


Usually we only attach Test Report on the out package of the cable, but we could also mark as your requirements, such as:
1. Company Name
2. Cross /Net weight
3. Drum No: XX
4. Cable Length : XX

Cable production throughout the chart

Cable Count Cable Diameter Cable Net
Weight		 minimum tensile strength
(N)		 minimum allowable Crush Load
(N/100mm)		 Minimum Bending Radius
(MM)		 Storage
Temperature
（mm) （Kg/km) Short term Long term short term long term Dynamic Static （℃）
2 4.0 35 1200 1500 3000 4000 80D 40D -40～80
4 4.0 35 1200 1500 3000 4000 80D 40D -40～80
6 5.0 40 1200 1500 3000 4000 100D 50D -40～80

G.652 50/125µm 62.5/125µm
Attenuation
(+20°C) (dB/km)		 @850nm ≤3.0 ≤3.0
@1300nm ≤1.0 ≤1.0
@1310nm ≤0.36
@1550nm ≤0.22
Bandwidth (Class A) (MHz·km) @850nm ≥600 ≥200
@1300nm ≥1200 ≥600
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc (nm) ≤1260



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
