CWDM 1290nm 10Gbps Dual LC Single Mode 40km XFP Transceiver Module with DDMI
CWDM 1290nm 10Gbps Dual LC Single Mode 40km XFP Transceiver Module with DDMI
- Support 9.95 Gbps to 10.5 Gbps
- Complaint with XFP MSA
- Compliant to IEEE 802.3ae 10GBASE-LR/LW
- Compliant to 10GFC 1200-SM-LL-L
- Compliant with XFI 10G Serial Electrical Interface
- Maximum Link Length of 40 km
- 2-Wire Interface for Integrated Digital Diagnostic Monitoring
- XFI Loopback Mode
- No reference Clock required
- Only Required +3.3 V Power Supply
- Power Consumption < 2W
- RoHS Compliant
- Part Number: XPC29-40D
- Device Type: XFP CWDM
- Package: XFP
- Data Rate: 10.3Gbps
- Wavelength: CWDM 1290nm
- Distance/Power Budget: 40km
- Optical Components
- LD: DFB
- PD: PIN
- Output Power: -1~4dBm
- Receiver Sensitivity: -16.5dBm
- Power Supply Voltage: 3.3V/ 5V
- Connector: Dual LC
- Fiber Type: SMF
- Operating Temperature: 0~70 °C
- DDMI: With
- Application: 10GBASE-ER/EW/ 10G FC
- Compatiblity: All Brands
F-tone is the original manufacturer of XFP CWDM XPC29-40D - CWDM 1290nm 10Gbps Dual LC Single Mode 40km XFP Transceiver Module with DDMI. We have ready stock for XPC29-40D and can ship it out in two business days. We guarantee the XPC29-40D transceiver module to work in your system and all of our XPC29-40D transceiver modules come with a lifetime warranty.
The XPC29-40D is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The XPC29-40D must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
