F-tone's fiber mirror is a passive device with compace size, which is disigned to reflect the light through original route. The Polarization Maintaining Faraday Mirror is manufactured mainly for sensing system, such as FOCT, Hydrophone, Gyro. The Faraday Mirro has such charateristics: compact size, high extinction ratio, high stability, etc.
Features & Applications
| Features | Applications |
|---|---|
| Low Insertion Loss | Fiber Optic Instruments |
| High Return Loss | Fiber Sensors |
| High Reliability | Fiber Lasers |
| High Stability | Coherent Detecting |
Specifications
| Parameter | Unit | Value |
|---|---|---|
| Center Wavelength | nm | 1080 |
| Operating Wavelength Width | nm | ±5 |
| Max. Insertion Loss at 23 ℃ | dB | 1.0 |
| Faraday Rotation Angle for CWL | deg | 45 |
| Max. Rotation Angle Tolerance at 23 ℃ for CWL | deg | ±3 |
| Min. Extinction Ratio at 23 ℃ (PM Fiber Type) | dB | 20 |
| Max. Polarization Dependent Loss at 23 ℃ (SM Fiber Type) | dB | 0.15 |
| Max. Polarization Mode Dispersion | ps | 0.05 |
| Max. Power Handling (CW) | W | 0.5, 1, 5, 10, 20 or Specified |
| Max. Peak Power for ns Pulse | kW | 10 or Specified |
| Package Dimension | mm | 64x28x26 |
| Max. Tensile Load | N | 5 |
| Axis Alignment | - | Both axis working |
| Operating Temperature | ℃ | -5~+70 |
| Storage Temperature | ℃ | -40~+85 |
Ordering Information
HPIFRM-①①①①-②-③③③-④⑤-⑥-⑦-⑧⑧⑨⑨ (SM Fiber Type)
①①①①
- Wavelength:
1080=1080nm, SSSS=Specified
②
- Rotating Angle:
1=45°, 2=90°
③③③
- Fiber Type:
003=PM980, 004=HI1060, 018=PM 10/125DCF, SSS=Specified
④
-
