18GHz High Dynamic DWDM Analog Optical Transceiver

Features
●Transmitter using butterfly optical device with TEC
●Support ITU C-Band，wide range of DWDM wavelengths can be selected
●Wide operating frequency from 10MHz to 18GHz
●Flat frequency response： ≤±1.5dB typical
●High RF input P-1dB：≥27dBm@10GHz
●Good noise figure：≤48dB@18GHz
●High dynamic range：SFDR up to 123dB·Hz2/3
●Automatic optical power control（APC）and auto temperature control（ATC）functions
●Excellent EMI/EMC design，ROHs compliant and CE certification
Applications
●Antenna remoting
●Satellite communication
●Delay line
●Distributed antenna system
●Wideband wireless communication
●OFDM fiber transmission

Absolute Maximum Ratings

Note：Operation beyond these absolute maximum conditions may degrade device performance, lead to device failure, shorter lifetime, and will invalidate the device warranty.

Typical Specification

Optical Receiver Laser Safety and ESD Protection

1,The laser safety level of the optical Tx modules is ClassⅢB (5mW~500mW). When using the Tx laser, the user has to avoid

to exposure to the beam.

2, The optical Tx and Rx modules have electrostatics sensitivity devices, so the user has to do a good job of ESD protection

when using the modules. Heat Dissipation Requirements

In order to ensure proper performance, heat sinking and heat removal must be provided by the user to limit maximum temperature of the transmitter module.
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networ
