Part Number: 200G-QSFP56-DAC0.5M
Mellanox MCP1650-V00AE30 Compatible 200G QSFP56 DAC (QSFP56 to QSFP56 PAM4 Direct Attach Cable 30AWG 0.5-meter)
The 200G QSFP56 Active Direct Attach Copper Twinax Cable is designed for use in 200GBASE Ethernet. They are suitable for very short links and Improve network efficiency for data center server and storage connections. This cable is compliant with IEEE 802.3cd by Ethernet standard and QSFP MSA Compliant. F-tone 200G QSFP56 DAC Cable, used in 200G Ethernet, InfiniBand HDR, data center, and storage area network.
Product Details
| Mellanox Compatible | MCP1650-V00AE30 | Vendor Name | F-tone |
|---|---|---|---|
| Connector | QSFP56 to QSFP56 | Max Data Rate | 212.5Gb/s |
| Wire Gages | AWG 30 | Cable Length | 50cm (1.6ft) |
| Jacket Material | PVC (OFNR) | Minimum Bend Radius | 35mm |
| Operation Temperature | 0~ 70 ～C (32 to 158～F) | Modulation Format | PAM4 |
| Protocols | IEEE 802.3bj and 802.3cd, SFF-8636 | Application | 200G Ethernet |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
