SFP, SFP+ & zSFP+, Cage Assembly, Data Rate (Max) 28 Gb/s, External Springs, EMI Enhanced, 1 x 4, None, Through Hole - Press-Fit Mount, 4 Port
Technical Specifications
| Part Number | 2294408-2 | Part Status | Active |
| Connector Style | Cage, Ganged (1 x 8) | Connector Type | zSFP+ |
| Data Rate (Max)(Gb/s) | 32 | Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit | Features | EMI Shielded |
| Port Matrix Configuration | 1x8 Ports | Number of Ports | 8 |
| Number of Positions | - | Connector Mounting Type | Board Mount |
| Operating Temperature Range | -40 – 85°C | Pluggable I/O Applications | - |
| Circuit Application | Signal | EMI Containment Feature Type | EMI Springs |
| Included Lightpipe | NO | Cage Material | Nickel Silver Alloy |
| Heat Sink Height | 4.2mm[.165in] | ||
| PCB Thickness (Recommended) | 2.25mm[.089in] | Tail Length | 2.05mm[.081in] |
