6GHz DSFP-RF 2T2R Analog Optical Transceiver

Features
● Two optical transmitter and two optical receiver integrated
● Innovative design of golden finger for RF transmission
● Pluggable LC/PC optical connector
● Wide operating frequency from 100MHz to 6GHz
● Automatic optical power control
● Both Tx and Rx have optical power monitoring function
● High dynamic input and output range
● I2C interface
● Low power consumption
Applications
● Distributed antenna system
● WiMAX /Wi-Fi/ 4G / 5G/ 6G
● Mobile backhaul
● GPS/BEIDOU signal transport
● Antenna remoting
Note：Operation beyond these absolute maximum conditions may degrade device performance, lead to device failure, shorter lifetime, and will invalidate the device warranty
Typical SpecificationNote: (1) Test with 1-meter SMF-28 fiber, without amplify.
Connector and Interface

Register Defines
Please Contact F-tone Networks Sales for the register file.
Heat Dissipation Requirements and Laser radiation warning
In  order  to ensure  proper performance, heat  sinking and  heat  removal must be provided by the user to limit maxim um temperature of the module  The maximum laser power is 0.5 watt(Class BⅡ). The user should avoid direct exposure to beamMechanical (unit: mm)
● Cover design refer to SFF-8432 Rev 5.0
● Tap requirement refer to SFF-8432 Rev 5.0, pull force >12.5N
● Optical port refers to IEC61754-20-2002
Ordering Information

Note:
(1) Other wavelengths can be customized;
(2) Other types of optical fiber connector type can be customized.
(3) see the Connector and Interface part(2)：“The relative position of Tx1/Rx1 and Tx2/Rx2 optical direction” for more details.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
