Part Number: 8FMTPLCOM4
MTP Female to LC UPC Duplex OM4 Multimode Harness Cable
MTP cables are your best choice for high density fiber networks. It's specifically designed for fast ethernet, fiber channel, data center and gigabit ethernet applications. This 8 Fiber harness cable is used for a direct connection between QSFP+ to (4) SFP+ ports with no patch panels or intermediate trunks in between.
Please Note: MTP is a registered trademark of US Conec Ltd. Attenuation testing performed in accordance with EIA/TIA-455-171A.
Product Specifications
| Connector A | MTP Female (pinless) | Connector B | LC UPC Duplex |
|---|---|---|---|
| Fiber Mode | OM4 50/125 m | Wavelength | 850/1300nm |
| Insertion Loss | MTP0.35dB, LC0.3dB | Return Loss | MTP 20dB, LC 30dB |
| Jacket OD | 3.0mm | Fan-Out Diameter | 2.0mm |
| Installation Tensile Load | 100 N | Long-Term Tensile Load | 50 N |
| Storage Temperature | -40C to +85C | Operating Temperature | -10C to +70C |
| Cable Jacket | LSZH | Fiber Count | 8 Fibers |
Quality Certification
Quality and standards are the foundation of F-tone. We are dedicated to providing customers with the outstanding, standards-compliant products and services.
F-tone has passed many quality system verification, like CE, RoHS, FCC, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service.
Please Note: Each cable is 100%optically inspected and tested for insertion loss before you receive it.
Highlights
8 Fiber MTP-LC Harness Cable
- High-quality cable with 3D interferometer tested MTP connector
- Low insertion loss and stable signal transmission ensuring your network safety
- For 40G QSFP+ SR4 to 4x10G SFP SR optics direct connection
MTP to 4 LC Connectors for High-Density Fiber Patching
0.35 dB Low IL MTP Connector
High-performanced MTP connector with 0.35 dB ultra low insertion loss.
0.3 dB Low IL LC Connector
The tightly tolerance ceramic ferrules ensuring consistent ultra low loss.
8 Fiber Counts Used
1-plug x 1-row applications, 4 Fibers used in each ends, requiring lateral signal transposition.
Heat Shrink Tube
A heat shrink tube divides the cable into four 2.0mm OD. fan outs, providing protections.
Used for a Direct Connection between QSFP+ to (4) SFP+ Ports
with No Patch Panels or Intermediate Trunks in Between
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
