Part Number: AD-E2000-LC-FF-SM-SX
E2000 to LC UPC Adapter Female to Female, Optic Fibre Adapter SM Fiber Coupler
Description:
Fiber Optical Adapter Series(Female-Female)
Fiber optical adapter uses a sleeve to precisely connect two side optical fiber connectors to allow optical signals to be transmitted at sufficiently low insertion loss. fiber optical adapter include: SC, LC, FC, ST, MU, D4, DIN, E2000, SMA and other series.
Features:
Precision connection with sleeve
SM and MM connector can be used interchangeably
Low insertion loss，High return loss
High interchangeability,High reliability,
Compliance with IEC and ROHS standards
High precision of mechanical dimensions
Parameter
| ITEM | (SM-9/125) | (MM-50/125) |
|---|---|---|
| (MM-62.5/125) | ||
| Insertion Loss | ≤0.2dB | ≤0.2dB |
| Retun Loss | PC≥45dB UPC≥50dB APC≥60dB | -- |
| Repeatability | 0.1dB Max. | |
| Temperature Range | -40℃~+75℃ | |
| Opertation Times | ≥1000 | |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
