Part Number: AD-SNU-SNU-SM-DX-FM
OS2 Singlemode 4-Port SN/UPC to SN/UPC Plastic Fiber Optic Adapter Without Flange
A fiber optic adapter, sometimes also called a coupler, is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines.
SN/UPC 4-port adapter is designed to fit through the same panel cutout defined for duplex LC adapters, allowing an instant 4x of the current module/panel connector density by simply removing the LC duplex adapters and installing the SN adapters.
Features
● ≤0.2dB (Typical) Low Insertion Loss
● Mates SN Standard, Junior and Compact Connectors
● Allows Up to 4 Times Higher Density Compared to Duplex LC Adapter
● 4 Independent Duplex Fiber Breakout at a Quad-style QSFP, QSFP-DD & OSFP Transceiver
● Color Coded for Rapid Identification of Single Mode Fiber Patterns
● Stainless Steel Clips for Tool-less Snap-in Installation
● 400G Networks for Hyperscale Data Centers
Specifications
| Connector Type | Senko SN-SN | Body Style | 4-Port |
|---|---|---|---|
| Polish Type | UPC | Fiber Mode | OS2 9/125μm |
| Insertion Loss | ≤0.2dB | Durability | 500 times |
| Mounting Type | Reduced Flanged | Alignment Sleeve Material | Zirconia Ceramic |
| Color | Blue | Flammability Rate | UL 94V-0 |
| Package Quantity | 1 Pc | RoHS Compliancy Status | Compliant |
| Operating Temperature | -40 to 85℃(-40 to 185℉) | Storage Temperature | -10 to 60℃(14 to 140℉) |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
