Analog Coaxial Photodiode
Features
●Small size 3 pin coaxial package
●High responsivity: typical 0.85 mA/mW@1550nm
●Wide operating frequency from 10MHz to 24GHz
●Wide wavelength range from 1100nm to 1620nm
Applications
●Antenna remoting
●GPS signal transport
●Wireless signal transport
●Distributed antenna system
●High speed test and measurement
●Video Signal Distribution in HFC and FTTx Nodes
Absolute Maximum Ratings
Electrical and Optical Characteristics (@25°C)
Note (1): Test with F-tone Networks optical source and modulator. The length of testing fiber is 1-meter. The ripple of pa ssband has deducted the ripple of optical source and modulator.
Test Curve
24G version S11 curve is not very good, if need better return loss performance, please choose DR02 series high speed photodiode.
Fiber Specification
Note(2): Other optical connectors are available upon request.
PIN Function
Mechanical (unit: mm)
With FPC (optional)
ESD protection
The device is ESD sensitivity, precautions for handling.
Ordering Information(3)
Note(3): Other optical connectors are available under customer’s request, as well as flexible printed circuit fitting for the device, please contact our sales for more information.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
