AVAGO AFBR-1528CZ Compatible Domestic Alternative Optical Module
product presentation
The FT-1528CZ/2528CZ series fiber optic transceivers are designed for use with 650nm plastic optical fibers (POF). They deliver high-performance and cost-effective fiber optic communication links for fields such as industrial, power generation, medical, transportation, and gaming applications, with an operating temperature of up to 95℃.
The FT-1528CZ/2528CZ series is fully compatible with AVAGO's AFBR-1528CZ/2528CZ series products. It supports industry-standard plastic optical fiber interfaces and features a horizontal structure. The transceivers are compatible with plastic optical fibers of 1mm diameter and PCS optical fibers of 200μm diameter; when paired with 1mm-diameter plastic optical fibers, the typical transmission distance can reach 110 meters.
The FT-1528CZ is a transmitter, encapsulated with a high-power LED chip with a peak wavelength of 650nm. When used with 1mm-core-diameter plastic optical fibers and driven by a 30mA current, its typical output optical power is -2dBm. The FT-2528CZ is a receiver, consisting of a high-gain transimpedance amplifier (TIA) integrated with a photodiode. Its output stage adopts a rail-to-rail structure, with a final output of TTL level. To enhance the stability of the receiver's output pulse width, the receiver chip is designed with an automatic pulse width calibration circuit, ensuring pulse width distortion is within ±20ns.
Product characteristics
● Data transfer rate: DC-10 MBd
● Power supply voltage supports 3.3V and 5V
● Typical transmission distance: 110 meters(Compatible with 1mm Plastic Optical Fiber)
● The output waveform and pulse width is stable
● Operating temperature range: -40℃ to 95℃
● Compliance with the RoHS criteria
Product application
● Factory automation
● Lan
● Audio and video applications / game applications
● Industrial network and fieldbus
● High-Voltage Isolation
Overall dimensions drawing (FT-1528CZ/2528CZ)
List of product models
|
Product model |
Description |
|
FT-1528CZ |
Transmitter |
|
FT-2528CZ |
Receive devices |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
