Part Number: CFP4-100GT85-1M
100GBASE-SR4 and OTN Multirate CFP4 850nm 100m Transceiver for MMF
F-tone.Com's CFP4-100GT85-1M-xx 100G CFP4 transceiver modules are designed for use in 100 Gigabit Ethernet links and 4x28G OTN client interfaces over multimode fiber. They are compliant with the CFP4 MSA and IEEE 802.3bm 100GBASE-SR4. Digital diagnostics functions are available via the MDIO interface.
Key Feature
- Hot-pluggable CFP4 form factor
- Supports 103.1Gb/s and 112Gb/s aggregate bit rate
- Power dissipation < 4W
- RoHS-6 compliant (lead-free)
- Single 3.3V power supply
- Maximum link length of 100m on OM4 Multimode Fiber (MMF)
- 4x28Gb/s 850mm VCSEL-based transmitter
- 4x28G electrical interface
- Single MPO12 receptacle
- MDIO management interface
- Commercial case temperature range: 0°C to 70°C
Applications
- 100GBASE-SR4 100G Ethernet
- 4x28Gbs/Multimode OTN
- Proprietary protocol and density application
- Ethernet switches and router applications
Packaging
- Antistatic bag
- Packed on pallets in a box(Default Customer Options)
- Specific Labels as Request
- Seperate white Box for each transceiver
OEM and ODM
Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.
- OEM/ODM order is available
- We can supply CFP4-100GT85-1M according to your requirements, and design CFP4-100GT85-1M label and packaging for your company. We welcome any inquiry for customized 100G optical transceiver.
Order Procedure
Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.
Shipment
International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
Save Cost By Buying 100G Optical Transceiver From Original Manufacturer F-tone Directly.
F-tone is a professional manufacturer supplier of 100G optical transceiver . All of our 100G optical transceiver are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee 100G optical transceiver to work in your system and all of our 100G optical transceivers come with a lifetime advance replacement warranty. If you have questions about 100G optical transceiver, please feel free to contact us at [email protected].
| Distance | 100 m |
| Data Rate (max) | 112 Gb/s |
| Protocol | OTN OTU4 Compliant 100G Ethernet Compliant |
| Low End Case Temperature (°C) | 0 |
| High End Case Temperature (°C) | 70 |
| Diagnostics:Digital | Digital |
| Transmitter | 4x VCSEL Array |
| Receiver | PIN |
| Voltage Supply | 3.3 |
| Connector | MPO (MTP12) |
| Wavelength | 850nm Band |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
