Cisco QSFP-100G-LR4-I Compatible 100GBASE-LR4 QSFP28 1310nm 10km LC Duplex SMF DDM Optical Transceiver Module (Industrial Temp.)

Cisco QSFP-100G-LR4-I Compatible 100GBASE-LR4 QSFP28 1310nm 10km LC Duplex SMF DDM Optical Transceiver Module (Industrial Temp.)

View full details

Cisco QSFP-100G-LR4-I Compatible 100GBASE-LR4 QSFP28 1310nm 10km LC Duplex SMF DDM Optical Transceiver Module (Industrial Temp.)

The Cisco industrial temperature QSFP-100G-LR4-I compatible QSFP28 optical transceiver module is designed with duplex LC connectors, reaching a link up to 10km over single-mode fiber(SMF). F-tone Networks manufactured 100GBASE-LR4 QSFP28 transceiver module is compliant with IEEE 802.3ba 100GBASE-LR4, QSFP28 MSA standard. Besides, DDM (digital diagnostics monitoring) function is supported on the 100G fiber optic transceiver to achieve real-time operating parameters monitoring. With these features, this 100G QSFP28 transceiver is widely applied in 100G telecom connections, data centers, high-performance computing networks, enterprise core and distribution layers, campus networks, etc.

Part Number

FT-QSFP28-LR4-I

Vendor Name

F-tone Networks

Form Factor

QSFP28

Data Rate

103.1Gbps

Wavelength

1310nm

Distance

10km

Connector

Duplex LC

Cable Type

OS2 SMF

Transmitter

LAN WDM EML

Receiver Type

PIN

TX Power(100G)

-4.3~4.5dBm

Receiver Sensitivity(100G)

<-10.6dBm

Power Consumption

≤4W

Temperature

-40 to 85°C (-40 to 185°F)

DDM

Support

Bit Error Ratio (BER)

1.00E-12

Protocols

IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm, QSFP28 MSA, SFF-8636

Warranty

3 Years

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

View all

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

View all

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
