This Cisco SFP-25GBX-D-10 compatible SFP28 transceiver provides 25GBase-BX throughput up to 10km over single mode fiber (SMF) using a wavelength of 1330nm-TX/1270nm-RX via an LC simplex connector. This bidirectional unit must be used with another transceiver or network appliance of complimenting wavelengths. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard.
Part Number: SFP-25GBX-D-10
Cisco SFP-25GBX-D-10 Compatible 25GBASE-D SFP28 BiDi 1330nm-TX/1270nm-RX 10km Simplex LC/UPC SMF Transceiver Module
Cisco SFP-25GBX-D-10 Compatible 25GBASE-BX10-D SFP28 Optical Transceiver Module for Data Center and Telecom (SMF, 1330nm-TX/1270nm-RX, 10km, LC, DOM)
Description
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Cisco Compatible | SFP‑25GBX‑D‑10 | Vendor Name | F-tone |
| Form Factor | SFP28 | Max. Data Rate | 25.78Gbps |
| Wavelength | 1330nm-TX/1270nm-RX | Max. Cable Distance | 10km |
| Connector | Simplex LC/UPC | Media | SMF |
| Transmitter Type | DFB BiDi | Receiver Type | PIN |
| TX Power | -2~4dBm | Minimum Receiver Power | <‑13dBm |
| Power Budget | 11dB | Receiver Overload | 2dBm |
| Max. Power Consumption | ≤1 W | Extinction Ratio | 3.5dB |
| DDM/DOM | Supported | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| CDR (Clock and Data Recovery) | TX & RX Built‑in CDR | Inbuilt FEC | No |
| Protocols | SFP28 MSA, CPRI, eCPRI | Warranty | 5 Years |
Matched Pairs: It must be used in pairs with SFP28 1270nm‑TX/1330nm‑RX.
Quality Testing Program
Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
