Juniper SFP-GE80KCW1530-ET Compatible 1000BASE 1530nm CWDM SFP 80km DDM Transceiver

Juniper SFP-GE80KCW1530-ET Compatible 1000BASE 1530nm CWDM SFP 80km DDM Transceiver

View full details

Part Number: CWDM-SFP1G-80D-D

1000BASE 1530nm CWDM SFP 80km DDM Transceiver Juniper SFP-GE80KCW1530-ET Compatible

The CSFP-1G53-80D single mode transceiver is small form factor pluggable module for duplex optical data communications such as Gigabit Ethernet 1000BASE-ZX and Fiber Channel 1x SM-LC-L FC-PI. This transceiver offers the same function with Juniper SFP-GE80KCW1530-ET and it is fully compatible with Juniper devices. It is with the SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of CWDM wavelength. The transmitter section uses a multiple quantum well CWDM DFB laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. The CSFP-1G53-80D series are designed to be compliant with SFF-8472.

Key Features

  • Data-rate of 1.25Gbps operation
  • Average Output Power:0~5dBm
  • Receiver Sensitivity:-24dBm
  • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
  • Compatible with SONET OC-24-LR-1
  • Compatible with RoHS
  • +3.3V single power supply
  • Built-in Digital Diagnostic Function
  • Commercial temperature range (COM): 0 to 70°C as default

Applications

  • Gigabit Ethernet
  • Fiber Channel
  • Switch to Switch interface
  • Switched backplane applications
  • Router/Server interface

Ordering Information

Part No. Data Rate (Gbps) Wavelength (nm) TX Power (dBm) Re Sens. (dBm) Transmission Distance Fiber Type Connector Type Temp. Range Digital Diagnostics
CSFP-1GXX-40 ≤ 1.25 1270 ~1610 -5~0 ﹤-24 40km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-60 ≤ 1.25 1270 ~1610 60km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-80 ≤ 1.25 1270 ~1610 0~5 ﹤-24 80km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-100 ≤ 1.25 1270 ~1610 0~5 ﹤-28 100km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-120 ≤ 1.25 1270 ~1610 2~7 ﹤-32 120km SMF LC Com./Ex./Ind. Yes/NO

Notes

  • XX means CWDM wavelength (27 = 1270nm, 29 =1290nm, 31 = 1310nm, 35 = 1350nm, etc., in 20nm increments)
  • F-tone also provide other 1.25G CWDM SFP transceivers with different transmission distances, like 60km.

Packaging

  • Antistatic bag
  • Packed on pallets in a box(Default Customer Options)
  • Specific Labels as Request
  • Seperate white Box for each transceiver

OEM and ODM

Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.

  • OEM/ODM order is available
  • We can supply CSFP-1G53-80D according to your requirements, and design CSFP-1G53-80D label and packaging for your company. We welcome any inquiry for customized CWDM SFP optical transceiver.

Order Procedure

Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.

Shipment

International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.

Save Cost By Buying CWDM SFP From Original Manufacturer F-tone Directly.

F-tone is an professional manufacturer & supplier of CWDM SFP transceivers. All of our CWDM SFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee CWDM SFP transceivers to work in your system and all of our CWDM SFP transceivers come with a lifetime advance replacement warranty. If you have questions about CWDM SFP optics, please feel free to contact us at [email protected].

Ordering Information

Part No. Data Rate (Gbps) Wavelength (nm) TX Power (dBm) Re Sens. (dBm) Transmission Distance Fiber Type Connector Type Temp. Range Digital Diagnostics
CSFP-1GXX-40 ≤ 1.25 1270 ~1610 -5~0 ﹤-24 40km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-60 ≤ 1.25 1270 ~1610 60km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-80 ≤ 1.25 1270 ~1610 0~5 ﹤-24 80km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-100 ≤ 1.25 1270 ~1610 0~5 ﹤-28 100km SMF LC Com./Ex./Ind. Yes/NO
CSFP-1GXX-120 ≤ 1.25 1270 ~1610 2~7 ﹤-32 120km SMF LC Com./Ex./Ind. Yes/NO

Notes

  • XX means CWDM wavelength (27 = 1270nm, 29 =1290nm, 31 = 1310nm, 35 = 1350nm, etc., in 20nm increments)
  • F-tone also provide other 1.25G CWDM SFP transceivers with different transmission distances, like 60km.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
