MPO Fiber Polishing Liquid AO/CO/SC 500ml

Part Number: DAOSO-LQ-FM

MPO Fiber Polishing Liquid & Slurry AO/CO/SC type, 500ml

CO / AO / SC series polishing liquid is a series of polishing liquid with micron or submicron cerium oxide, alumina, and silicon carbide as abrasives. This series of products has the characteristics of good dispersion, uniform particle size, and high polishing efficiency, which can meet the precision polishing of high-precision optical instruments, glass-ceramic-based hard disk substrates, magnetic heads, compound crystals, ceramics, fiber optic connectors, hard alloys, etc Claim.

Specifications:

Series Model Size (D50, μm) Application
CO series CO-1 / 4 0.2-0.3 Optical glass grinding and polishing
CO-1 / 2 0.4-0.6 MT fiber optic connector, optical glass, various lenses, etc.
CO-1 0.8-1.2
AO series AO-1 / 2 0.4-0.6 optical fiber connector, crystal (Si, Ge, GaAs, InP, SiC), hard disk substrate, ceramic, hard alloy, stainless steel and optical glass, etc.
AO-2 1.6-2.4
AO-3 2.6-3.6
SC series SC-1 0.8-1.2 optical fiber connector, hard disk, ceramic, hard alloy, various gems and optical glass, etc.
SC-3 2.6-3.6

Note: We can also provide polishing solutions with different concentrations and particle sizes according to the special needs of customers.

Instructions for use:
1. Shake well before use;
2. It can be used after diluting to the appropriate concentration according to the specific grinding conditions.

Packaging specifications:
50ml / bottle, 250ml / bottle, 500ml / bottle

Storage conditions:
Transport and storage temperature is 5-35 ° C.

Application areas:
1. Phosphor powder, high pressure sodium tube, catalyst carrier, nano electroplating industry, transparent sintered body, precision polished bioceramics, electronic ceramics, fine grinding and polishing, etc.
2. Large size sapphire single crystal, laser crystal, optical interface and other optical crystal fields.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
