Part Number: DVP
Nanjing DVP 730H FTTH Drop Cable Fusion Splicer
Description:The DVP-730H is used in various working conditions for field fiber splicing and can splice any type of fiber optic cables .
The device is supplied with a kit of miscellaneous tools and accessories. Due to the long battery life and both side operation option ,
the Fusion Splicer DVP-730H keeps operating even in the toughest environments.
This offer provides superior quality at an affordable price.
Main Features:Color LCD monitor and 256x magnification
Compact & light weight
Reversible monitor with control panels on each side
Max. wind velocity of 15 m/s.
9 Sec. splice time , 40 Sec. tube-heat time
Simultaneous X and Y views
Large capacity internal battery pack with a charger
SYSTEM TEST ensures the best working condition
User programmable
Auto check fiber end face
Auto calibrated parameters
Stores 8000 splice results
Multiple language interface
Standard equipment:
| Key | Description | QTY |
|---|---|---|
| 1 | DVP 730H FTTH Fusion splicer | 1 |
| 2 | Rechargable Li-battery pack | 1 |
| 3 | AC adapter | 1 |
| 4 | AC power cord | 1 |
| 5 | Battery charger | 1 |
| 6 | Spare electrodes | 1 |
| 7 | Instruction manual (English) | 1 |
| 8 | Heavy-duty carrying case | 1 |
| 9 | Cooling salver | 1 |
| 10 | Charger cord | 1 |
| 11 | High precision cleaver (tool life: 18 000 cleave operations) | 1 |
| 12 | Clauss CFM-2 stripper | 1 |
| 13 | Fiber Holders | 1 |
Technical Parameter:
| Applicablefibers | Singlemodeandmultimodesilica-baseopticalglassfiber:FTTH,SM,MM,DS,NZ-DS,EDF |
|---|---|
| Claddingdiameter | 100-150µm |
| Coatingdiameter | 100-1000µm |
| Cleavelength | 16mm(standard) |
| Averagespliceloss | Singlemodefiber:Typ.0.02dB |
| Dispersionshiftedfiber:Typ.0.04dB | |
| Multimodefiber:Typ.0.01dB | |
| Returnloss | ≥60dB |
| Averagesplicetime | Typ.9seconds |
| Fiberprotectionsleeveshrinkingtime | 40mm/60mmsleeve:Typ.40seconds |
| Protectionsleevelength | 20mm,40mm,60mm |
| Battery/charger | Inputpower:85∼260V,(47∼63Hz) |
| Outputpower:9∼3V,10Ah,upto150timesofcontinuoussplicesandheats | |
| DCadaptor | 12Vvoltage,optionalmultipurposeexternalbattery |
| Tensiontest | 2.0N(standard),average1,96N(200gf) |
| Programtest | Atmosphericpressure(maximumaltitude:5000m),temperatureandhumidity.AutomaticcalibrationbyobservingdistanceoftheGAPduringarcdischarge. |
| Typesofsplicingmode | Auto&Manual |
| Splicingprograms | FTTH,SM,MM,DS,NZ-DS,EDF |
| Storageofspliceresults | 8000spliceresultsintheinternalmemory |
| Interface | RS232interface&videooutput |
| Interfacelanguages | English |
| Operationconditions | -25~+50°C(temperature),0~95%(humidity),0~5000m(altitude),15m/s(maximumallowedwindvelocity) |
| Storageenvironment | -40~+80°C(temperature),0~95%(humidity) |
| DVP-730dimensions | 170(W)x140(H)x170(D)mm |
| DVP-730weight | 3.3kg |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
