Part Number: FAOC-LC-MM-P-FM
LC/UPC Multimode Pre-polished Ferrule Field Assembly Connector Fiber Fast/Quick Connector 0.9mm
Pre-polished Ferrule Fiber Fast Connector
The LC/UPC fast connector are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and a proprietary index-matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fibers.
The Field Assembly Connector series are already a popular solution for optical wiring inside buildings and floors for LAN & CCTV applications and with the expansion of FTTH, is already proving itself to be the connector of choice by incumbents, municipalities, utilities & alternative carriers. Our Field Assembly Optical Connector series are now available in SC, LC, or FC variants, catering for 250um to 900um, and 2.0mm, 3.0mm diameter single mode and multimode fiber types, including Multi-mode 62.5/125um and Multi-mode 50/125um. The single-mode versions are available with SPC or APC ferrules.
Product Specification
| Connector Type | LC | Polishing | UPC |
|---|---|---|---|
| Ferrule | Ceramic | Fiber Mode | 62.5/125µm OM1, 50/125µm OM2 |
| Cable Diameters | 0.9mm | Dimension | 50mm |
| Insertion Loss | ≤0.35dB | Return Loss | ≥45dB |
| Tension Test | ≥100N | Operating Temperature | -40 to 75°C (-40 to 167°F) |
2.Since FC type is special, please contact F-tone for more details.
Quality Certifications
Product Highlights
Key Features & Applications
Structure Example
Installation Procedure
Always make sure the fast connectors and optic fiber are clean and clear of any debris.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
