Part Number: FAP-SMM-8STSDX
8 Ports ST Panduit Opticom Compatible Fiber Adapter Panels (FAPs)
Compatible with:
Panduit Opticom ™ Angled Rack Mount Trays and Fiber Adapter Patch Panels
- 1RU FTT1A with CFAPPBL1A
- 2RU FTT2A with CFAPPBL2A
- 1 RU FTT1 with CFAPPBL1
- 2 RU FTT2 with CFAPPBL2
- 1 RU FRME1U
- 2 RU FRME2U
- 3 RU FRME3
- 4 RU FRME4
- 1 RU FCE1U
- 1 RU open access FCE1UA
- 2RU FCE2U
- 4 RU FCE4U
Opticom ™ Standard Rack Mount Trays and Fiber Adapter Patch Panels
Opticom ™ Rack Mount Enclosures
Opticom ™ Rack Mount Fiber Cassette Enclosures
Dimensions(inch)
Key Features and Benefits
- Panduit® Opticom® Compatible
- Meet or exceed TIA/EIA-568-C.3 requirements
- Provides a complete system solution for connectivity
- Available in 2,3,4,6,8,12,16,18 ports
- Horizontal and vertical MPO adapters, LC,Keyed LC, SC, ST
- TIA/EIA-604 FOCIS compliant or compatible simplex or duplex
- Allows for the industry's highest patch field density and fiber counts
- Assures flexibility and ease of network deployment and moves, adds, and changes
- Available in compatible with all Panduit LC, SC, ST and MPO fiber adapter panels and cassettes
F-tone.Com ST Panduit Opticom Compatible Fiber Adapter Panels(FAPs)
| 6 Port ST Panduit Opticom Compatible (FAPS) | |||||
| F-tone FAPS# | FIBER TYPE | DUPLEX & SIMPLEX | POLISH | SPLIT SLEEVERS | MFG PART# |
| FAP-SMM-6STSDX | |||||
| OM1 OM2 | Simplex | UPC | Phosphor Bronze | FAP6WST | |
| OM3 OM4 | Simplex | UPC | Zirconia Ceramic | FAP6WSTZ | |
| OS1/OS2 | |||||
| 8 Port ST Panduit Opticom Compatible (FAPS) | |||||
| F-tone FAPS# | FIBER TYPE | DUPLEX & SIMPLEX | POLISH | SPLIT SLEEVERS | MFG PART# |
| FAP-SMM-8STSDX | |||||
| OM1 OM2 | Simplex | UPC | Phosphor Bronze | FAP8WST | |
| OM3 OM4 | Simplex | UPC | Zirconia Ceramic | FAP8WSTZ | |
| OS1/OS2 |
Any Type Any Size All at F-tone.Com
- F-tone offers Panduit compatible adapter plates for use in many of our inside and outside plant enclosures.
- CMultimedia modular panels allow customization of installation for applications requiring integration of fiber optic and copper cables.
- Opticom® Fiber Optic Adapter Panels (FAPs) are used with Opticom® Rack and Wall Mount Enclosures, Fiber Adapter Patch Panels, and Opticom® Zero RU Fiber Adapter Panel
- As the best OEM Fiber Adapter Panel manufacturer, F-tone provides a wide range of quality Fiber Adapter Panel with detailed specifications displayed for your convenient selecting.
MAKE TO ORDER (Options)
| Connector | Dimension | Fibers | Polish | Fiber Type | Pack | Material | Color |
|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
For assistance customizing your Adapter Panel, please call us at +86-1-86-2786-1199 or email to [email protected].
Packaging of Fiber Adapter Panels
F-tone provides exquisite appearance, high quality packaging for fiber adapter panels at different sizes, this packaging can protect your product from getting damaged largely. What’s more,the logo on the packaging can be customized as requirement.
| Application | Multimode |
|---|---|
| Connector Type | ST |
| No. of Port | 8 Ports |
| Color | Vermeil |
| Material of Plates | C.R.S. Powder Coated |
| Material of Sleeves | Zirconia Ceramic |
| Finish | Powder Coated in Central Office(Black) |
| FAP Orientation | Horizontal |
| Vertical | |
| Dimensions(inch) | 4.30*1.38*1.16(L*W*HD) |
| Package | Carton |
Notes:
- If customized, please contact at [email protected]
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
