2M Step-Index Multimode Fiber Patch Cables SMA to SMA Ø25µm, 0.1NA, Low OH

2M Step-Index Multimode Fiber Patch Cables SMA to SMA Ø25µm, 0.1NA, Low OH

View full details

Part Number: FG025LJA-2

Step-Index Multimode Fiber Patch Cables SMA to SMA Ø25µm, 0.1NA, Low OH, 2M Length

Features

  • Numerical Apertures from 0.10 to 0.50
  • Cables Available for Wavelengths from 250 nm to 2400 nm
  • Available in Lengths up to 20 m
  • SMA905 Connectors on Both Ends
  • Ø3 mm, Ø3.8 mm, or Ø5 mm Outer Jacket
  • Custom Cables Available

Applications

  • Spectroscopy
  • Illumination
  • LED Energy Transmission
  • Medical Instruments
  • Optogenetics

Ø25 µm, 0.1 NA, Low OH, SMA to SMA Fiber Patch Cables

Fiber Core
Diameter		 NA Cladding
Diameter		 Coating
Diameter		 Wavelength Range Attenuation Plot Jacket
FG025LJA 25 ± 3 µm 0.100 ± 0.015 125 ± 2 µm 245 ± 10 µm 400 - 550 nm and 700 - 1400 nm FT030 (Ø3 mm)




This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
