Part Number: FHD-2UFRME
High Density FHD Series Fiber Optic Enclosure Unloaded
Fiber Enclosures For 10/40/100G Solution in Data CenterMaking Your Data Center Connection Simpler, Eaiser and Cost-Efficient.
Learn More
F-tone offers 2RU rack mount enclosure, which can house 6 pcs FHD series fiber adapter panels. It provides high density flexible system for managing fiber terminations, connections, and patching in datacenter application to maximizing rack space utilization and minimizing floor space.
| Part Number | FHD-2UFRME | Fiber Count | Max.144 Fibers |
|---|---|---|---|
| Enclosure Type | Rack Mountable | Material | SPCC (Black Coating) |
| Installation | Standard EIA 19' Rack Rails | Dimensions (HxWxD) | 3.46"x17.38"x14.37"(88x441.45x365.08mm) |
| Compliant | TIA/EIA-568-C.3 | Advantage | High Density Patching System |
Product Highlights
Black Powder Coated SPCC Rugged Heavy-Duty Steel Housing
Front Access, Removable Bi-Directional Doors w/A Push-Type Drawer
Designed for 6 pcs FHD Series FAPs
Installation of FHD Fiber Enclosure
Accessories Included in Fiber Enclosure
Each enclosure is shipped with an accessory pack that includes mounting screws, slack spools, bend radius control clips for proper installation and cable ties for cable management.
Accessories Optional for FHD Series Enclosure
Multi-Style Mounting and High-Density Installed in 10G/40G/100G Storage, Telecom and Data Center Housing
-
-
FHD-FOSM 24F Splice Tray Optional
-
-
FHD Series 24F Adapter Panel Optional
-
-
FHD Series MTP Adapter Panel Optional
| Image | Part Number | ID# | Description | Price | |
|---|---|---|---|---|---|
| FHD Adapter Panels | |||||
| FHD-FAP12LCDXSMF | 35488 | Fiber Adapter Panel with 12 LC Duplex OS2 Singlemode Adapters (Blue), Zirconia Ceramic | US$ 11.00 | Add to Cart | |
| FHD-FAP12LCDX10GMM | 41998 | Fiber Adapter Panel with 12 LC Duplex OM3/OM4 Multimode Adapters(Aqua), Zirconia Ceramic | US$ 12.00 | Add to Cart | |
| FHD-FAP6SCDXSMF | 35484 | Fiber Adapter Panel with 6 SC Duplex OS2 Singlemode Adapters (Blue), Zirconia Ceramic | US$ 8.00 | Add to Cart | |
| FHD-FAP6SCDZ10GMM | 51284 | Fiber Adapter Panel with 6 SC Duplex OM3/OM4 Multimode Adapters (Aqua), Zirconia Ceramic | US$ 9.00 | Add to Cart | |
| FHD-FAP8MTPHA | 35508 | Fiber Adapter Panel with 8 MTP(12/24F) Key-up/Key-down Adapters (Black), Horizontal | US$ 74.00 | Add to Cart | |
| FHD-FAP12MTPHA | 35510 | Fiber Adapter Panel with 12 MTP(12/24F) Key-up/Key-down Adapters (Black), Horizontal | US$ 110.00 | Add to Cart | |
| Cable Management and Splicing Accessories | |||||
| FHD-FOSMF-24F | 64246 | 24 Fiber Optical Splice Tray for FHD Fiber Enclosure | US$ 15.00 | Add to Cart | |
| FHD-FOSMF-12F | 64247 | 12 Fiber Optical Splice Tray for FHD Fiber Enclosure | US$ 14.00 | Add to Cart | |
| FHD-FTS | 64569 | 2 Packs Fiber Slack Management Spool for FHD Fiber Enclosure | US$ 3.00 | Add to Cart | |
| FHD-FEBRC | 64570 | 2 Packs Bend Control Clip for FHD Rack Mount Fiber Enclosure | US$ 1.80 | Add to Cart | |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
