Part Number: FOCML-50S
Fiber Optical Cable Manufacturing Line - FTTH Fiber drop cable Simplex/Duplex/Mini Fiber Optic Cable Production Line w/ PLC+IPC control
Applied in production of FTTH terminal optical fiber cable(drop cable), simplex/duplex 2mm and 3mm,12F/24F Mini extrusion material is PVC/LSZH. The extruded sheath possesses the features of even diameter, smooth, fast speed. And low excess loss for optical fiber.
Technical parameter of full line
| 1. | No. Of optical fiber pay off： | 24 |
|---|---|---|
| 2. | Tension of pay off： | 0.4～1.5N±0.05N |
| 3. | Reel of optical fiber pay off： | 25km and 50km standard fiber reel |
| 4. | No. of reinforcement pay-off rack： | 2 |
| 5. | Specification of reinforcement pay-off reels： | PN400 reels and ø254×ø116×180×ø32 reels |
| 6. | Reinforcement Specification： | ø0.45mm |
| 7. | Pay-off tension of reinforcement： | 5N-20N |
| 8. | Extruder size： | Φ50x25D |
| 9. | Final product： | FTTH drop cable(2.0*3.0mm, 2.0*5.2mm) simplex/duplex cable(2.0，3.0mm) Mini cable (3.0mm) |
| 10. | Structure speed： | Max 150m/min |
| 11. | Production speed： | 100--120m/min |
| 12. | Center height of machine： | 1000mm height from ground |
| 13. | Precision of meter-counter： | ≤0.2％ |
| 14. | Additional loose after extrusion： | ≤0.02dB/km(average value: 0.01 dB/km) |
| 15. | Power： | Approximate 58KW |
| 16. | Weight： | 5 ton |
| 17. | Line length： | 28M |
| 18. | Machine power： | 380V 50HZ three phase five wire |
| 19. | Line direction： | It’s up to customer |
| 20. | Range of air pressure： | 0.5-0.6MPa |
| 21. | Machine color： | It’s up to customer |
| 22. | Take-up tension: | 5-20N |
| 23. | Take-up reels Specification: | 400 reel and 630 reel(central shaft hole diameter ø 56) |
Main equipment part
| 1-1 | 12 heads optical fiber motorized pay-off(No.: 12GQZDFX-00) | 2set |
|---|---|---|
| 1-2 | SZ ocilaater | 1set |
| 1-3 | 2heads optical fiber motorized pay off rack and 2heads FRP/steel wire pay off rack(No.: 4TZDFX-01) | 1set |
| 2. | 800 single head motorized pay-off rack with straighten (No.:800GSZDFX-01) | 1set |
| 3. | 12 heads aramid yarn pay off(No.: 12TFLFX-00) | 1set |
| 4. | Mobile positioning mold support(No.:MJT-01) | 1set |
| 5. | Φ50x25D Extrusion main motor (No.:50JSJ-02) | 1set |
| 6. | 50KG Dryer machine and automatic hopper | 1set |
| 7. | Electric apparatus, main temperature control cabinet (IPC+PLC control)（No.：50PXGKDX-00） | 1set |
| 8. | 2.5m moving water trough with water tank and warm water tank （No.：2.5MYDRSC-00） | 1set |
| 9. | 8m single-layer U-type fixed type cooling water trough and water tank (with drying device)（No.：8MLQSC-00) | 1set |
| 10. | Industrial chiller（No:4PZLJ-00） | 1set |
| 11. | Shanghai Gongjiu laser diameter gauge | 1set |
| 12. | Φ640mm+300mm double-wheel capstan（No.：640QY-00） | 1set |
| 13. | Ink-jet printer stand device without ink-jet printer(No.:PMJZJ-01) | 1set |
| 14. | 9m horizontal tension wire accumulator with linear slide（No.：9MCXJ-00） | 1set |
| 15. | Φ400～630mm double-shaft take-up machine（No.：400SZSX-00） | 1set |
Specification and technical parameter of each equipment part
1. 12 heads optical fiber motorized pay-off rack with electricity removed device
(1). Pay-off type: suspended-shaft type motorized pay-off, every shaft is treated with quenching and tempering. Drum is clamped with quick lock,every pay-off unit can be controlled by switch independently.
(2). Drive: 12 sets 750w Shanghai ruishun AC motor+Danfoss transducer
(3). Tension control: pay-off dance wheel control and it has a up and down limit, fault alarm and automatically stop while alarm. The surface of all guide wheels are treated with anodizing and channel of wheel are smooth.
(4). No. of pay-off drum: 12 pieces of drums
(5). Bare optical fiber diameter: Φ0.25～Φ0.254mm;
(6). Pay-off tension: 0.3N～1.5Ｎ±0.05Ｎ
(7). Pay-off drum size: Φ236×Φ25.4×108mm（25KM drum）
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
