FT-27-TMM Series Multimode Fiber DTS Demodulator High-Precision Real-Time Temperature Monitoring for Critical Assets
Congratulations to Professor Huijuan Wu of F-tone Networks, who has been selected to the Stanford University World’s Top 2% Scientists List for four consecutive years from 2022 to 2025.Specializing in DAS, DTS, DVS and DSS distributed fiber optic sensing systems, Professor Wu leads our core R&D team with world-class academic achievements in fiber sensing technology. Every DAS interrogator we supply is backed by our independent, cutting-edge self-developed algorithms and hardware, delivering ultra-stable, high-precision long-distance monitoring performance for global industrial clients.
The FT-27-TMM multimode fiber-compatible DTS (Distributed Temperature Sensing) interrogator is a rack-mount, high-precision continuous distributed fiber temperature monitoring unit independently developed and manufactured by our company for multimode fiber applications.This unit enables full-length continuous distributed temperature profiling along the optical fiber.
The FT-27-TMM temperature interrogator adopts a customized design for superior light source stability and enhanced APD detection sensitivity. Equipped with industry-leading high-resolution, ultra-high-speed analog-to-digital (ADC) conversion and signal processing circuits, it achieves industry-leading performance across core technical indicators including maximum sensing distance, spatial resolution, temperature measurement accuracy and response speed.
Product Advantages
- Ultra-high temperature measurement accuracy
- Rapid temperature response speed
- Superior spatial resolution
- Extended sensing distance up to 20 km
- Highly robust embedded industrial design
Applications
- Tunnel & underground space fire alarm detection
- Oil & gas pipeline thermal leak inspection
- Storage tank & power cable fire monitoring
- Dam full-section temperature profiling
- Industrial fire safety monitoring
Model-Specific Specifications
| Model | Single Channel Sensing Distance | Spatial Resolution | Temperature Measurement Range | Single Channel Measurement Time |
|---|---|---|---|---|
| FT-27-TMM053 / FT320 | 5 km | 3 m | -10 ℃ ~ 120 ℃ | 3 s |
| FT-27-TMM053UH | 5 km | 3 m | 10 ℃ ~ 300 ℃ | 3 s |
| FT-27-TMM103 | 10 km | 3 m | -10 ℃ ~ 120 ℃ | 5 s |
| FT-27-TMM101 | 10 km | 1 m | -10 ℃ ~ 120 ℃ | 15 s |
| FT-27-TMM154 | 15 km | 4 m | -10 ℃ ~ 120 ℃ | 15 s |
| FT-27-TMM151 | 15 km | 1 m | -10 ℃ ~ 120 ℃ | 30 s |
| FT-27-TMM201 | 20 km | 1 m | -10 ℃ ~ 120 ℃ | 30 s |
General Specifications for All Models
| Item | Parameter Value of FT-27-TMM Multimode Fiber Series |
|---|---|
| Number of Channels | 1 channel |
| Temperature Resolution | 0.1 ℃ |
| Temperature Measurement Accuracy | ±1 ℃ |
| Positioning Accuracy | 1 m |
| Operating Temperature Range | -25 ℃ ~ 60 ℃ |
| Storage Temperature | -60 ℃ ~ 70 ℃ |
| Power Supply | AC 180 V ~ 240 V, 50 Hz ± 5 Hz |
| Optical Interface | FC/APC |
| Communication Interface | 10/100/1000 M adaptive Ethernet, RJ45 port |
| Secondary Development Interface | Dynamic link library provided for secondary development and system integration |
| System Software | Windows 2000 and above |
| Alarm Zones | Configurable via software |
| Dimension | Standard 19-inch 2U rackmount chassis |
| Weight | 5.8 kg |
| Product Compliance | Compliant with EMC, environmental reliability, functional and performance test standards |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
