Part Number: FT-3000A-MF-S2/X5
FT-3000A-MF-S2/X5 Dual Test Fiber Transceiver Endface Integrated Microscope
Description
- 400X magnification, 0.5 μm resolution, 200X magnification, 0.75 μm resolution, Or 80X magnification, 2μm resolution.
- Diameter on 8" inch display, 400X: Φ80mm, 200X: Φ39mm
- Illumination intensity adjustment button to identify the fiber core easily and clearly
- X, Y axis adjustment control is smooth, no beat, no offset and focus unchanged under manual mode
- Clear and bright image, average and even light spot for transparent and true fiber end face display.
- Optional assorted adaptors for PC/APC end surface inspection
- Optional built-in USB output to connect computer or SD card storage
- Optional IEC/IPC image analysis software 95% accuracy and 99% consistency for analysis.
Configuration
- FT-3000A-MF-S2/X5 Transceiver host 1pcs
- SC-F, LC-F Adaptor 1pcs/type (test SC/LC PC transceivers)
- 12VPower Supply 1pcs
- User manual 1pcs
- Warranty Card 1pcs
| Model | Feature | Description |
|---|---|---|
| FT-3000A-MM-S4/X3 | Manual Focus | FT-3000A-MM-S4/X3 for Patch cord, jumper fiber inspection; |
| FT-3000A-MF-S2/X5 | Auto Focus | FT-3000A-MF-S2/X5 for transceiver fiber inspection; |
| FT-3000A-MM-S2/X3 | Auto Focus Analysis | FT-3000A-MM-S2/X3 for mpo inspection; |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
