Chassis for 3G-SDI Video to Fiber Optical Converter Transmitter or Receiver

Part Number: FT-3GSDI-CHR-X

16 Slot Empty 2U Chassis for holding 3G-SDI Video to Fiber Optical Converter, supports Transmitter or Receivers

Overview

The Serial Digital Interface (SDI) is a digital video interface standard developed by the SMPTE organization.For example, the ITU-R, the BT.656, SMPTE. 259M defines a digital video interface for broadcast level; a famous HD serial digital interface standard (HD-SDI) that provides a data rate of 1.485 Gbit/s. A double-link HD-SDI standard is defined in the SMPTE 372M , the interface consists of a pair of SMPTE 292M links, capable of providing a 2.970 Gbit/s data transfer rate.The interface widely used in digital cinema or HDTV HDTV 1080P, it can have better fidelity and resolution than conventional HDTV. In the recent years, the interface 3G-SDI consisting of a single 2.970 Gbit/s serial link is defined in SMPTE 424M, which will replace the double-link HD-SDI.

These standards are used to transmit uncompressed, unencrypted digital video signals in broadcast television devices, which may also be added as necessary embedded audio and time code.Coaxial cable transmission, the distance is generally less than 300m.The fiber specification as defined by the SMPTE 297M can be long-distance transmission is limited to the maximum fiber length or repeater.Usually, SDI and HD-SDI are applied to professional vision only .In frequency devices, various license agreements limit unencrypted digital interfaces, banning them from using consumer devices such as Blu-Ray and individuals use in video CR.

SDI Standard List (colored as supported)

Advantages

It is a no compression, no delay of radio and television level optical terminal machine, pure hardware architecture, strong stability, high compatibility, anti-interference, support for pathological code module use;

It is highly flexible, on the basis of it can be based on different application scenarios, add video, independent audio, data, ethernet, telephone, contact closure and other functions.Plug and plug type board card design, can be mounted on a 2U chassis, convenient user unified management, maintenance;

It standard transmission distance can be up to 20KM, optical module single multi-mode compatibility, plug and plug optical module design, can be used according to the actual needs of the site can replace the optical module, it is simple to operate, plug and play, without debugging;

It is widely used in long-distance radio and television, medical surgery system, high-quality video and audio transmission system, remote multimedia teaching, video conference system, urban intelligent traffic monitoring system (ITS), safe city, military communication, military monitoring;

Features

1.Comply with DVB-ASI, SMPTE424M, SMPTE292M, and SMPTE259M (C) standards;

2.Use full digital processing technology, clear image, no color phase difference;

3.With APC circuit, constant output optical power, large dynamic range;

4.CWDM technology to achieve multi-channel signal transmission, large capacity, easy to upgrade;

5.The input has a cable balance to compensate for the loss of cable transmission;

6.With the output clock recovery reduction signal jitter circuit, it can handle the distortion signal very well;

7.Input / output cable transmission distance of up to 80m (BELDEN8281 cable);

8.Industrial grade design, modular design makes the equipment reliable and flexible;

9.Single multi-mode compatibility, no relay distance of up to 20 kilometers;

10.Wall-mounted, 1U rack type, plug-in card design, support 2U 16 slot chassis, double backup power supply;

11.Support for pathological signal (optional):

PLL signal; to detect the locked state of the SDI phase-locked loop.Ensure that the phase-lock ring of the optical terminal can work normally without locking in any scene;

Equalizer signal; it will truly reflect the design state of the equalizer.Effectively balance and process the coaxial cable signals of different distances within a certain range to ensure the integrity of the signals;

SDI Matrix signal; synthesize the above two signals.No matter day or night, the images generated by any scene can ensure the effective transmission;

12.Plug and play, no setup required;

13.Devices are used in pair. note that devices are distinguished between transmitter and receive;

Technical Indexes

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
