Part Number: FT-4012DR
12 fiber Ribbon Fiber Fusion Splice Protection Sleeves with Double Ceramic 40mm 50pcs/pkg
Description
This product Fiber Splice Protection Sleeve is made up of cross linked polyolefin heat-shrinkable tubes,hote melt tubes and Stainless steel needle. It is specifically designed for the protection of fiber optical closure.
Features
- Protect connection point,improve the mechanical strength,it is most reliable way to protect the fusion.
- Esay to operate,reducing the risk of fiber damage during installation
- Transparent tube,it is easy to see the status of fiber optical closure
- Min.shrinks temperatuer:120℃,shrink very fast and very easy to installation
- Work temperature high (-55°C~100°C), widely used
- Sealing structure let closure have good resistance to temperature and humidity performance.
Ordering Information
| Type | 4~6 fiber Single Ceramic Bar | 4~6 fiber Double Ceramic Bar | 8~12 fiber Single Ceramic Bar | 8~12 fiber Double Ceramic Bar | |
| Outer Tube | Outer Diameter | 4.4±0.1 | 4.8±0.1 | 5.8±0.1 | 5.8±0.1 |
| Thickness | 0.2±0.05 | 0.2±0.05 | 0.25±0.05 | 0.25±0.05 | |
| Length | 42.0±1 | 42.0±1 | 42.0±1 | 42.0±1 | |
| Material | Flexible Polyolefin | Flexible Polyolefin | Flexible Polyolefin | Flexible Polyolefin | |
| Inner Tube | Inner Diameter | 2.6 x 1.6±0.1 | 2.6 x 1.6±0.1 | 3.5 x 2.2±0.1 | 3.5 x 2.2±0.1 |
| Length | 0.3±0.1 | 0.3±0.1 | 0.5±0.1 | 0.5±0.1 | |
| Thickness | 40.0±1 | 40.0±1 | 40.0±1 | 40.0±1 | |
| Material | EVA | EVA | EVA | WVA | |
| Ceramic Bar | Diameter | 3.0±0.2 | 3.0±0.2 | 4.0±0.2 | 4.0±0.2 |
| Length | 40.0±0.5 | 40.0±0.5 | 40.0±0.5 | 40.0±0.5 | |
| Amount | 1 | 2 | 1 | 2 | |
| Material | 95 Ceramic | 95 Ceramic | 95 Ceramic |
Quantity per package: 50pcs/pkg
Note: We also provide this kind of protection sleeves with 1000pcs/pkg and good price.
Fiber optic splice protection sleeves are used for optical fiber fusion protection, it can protecting and supporting the fusion splice point. F-tone.com now provides different sizes and materials of this kind of products. And if you can not find the fiber optic splice sleeves you need on our website, welcome to contact us, we will give you a reasonable suggestion.
| Item | Test method | Performance |
|---|---|---|
| Temperature | IEC216 | -55°C~100°C |
| Tensile strength | ASTM D 2671 | 18MPa |
| Elongation at break | ASTM D 2671 | 700% |
| Density | ISO R1183D | 0.94g/cm3 |
| Dielectric strength | IEC243 | 25kV/mm |
| Volume resistance | IEC243 | 1015Ω |
| Dielectric constant | IEC243 | 2.5 |
| Longitudinal change | ASTM D 2671 | ±5% |
| Eccentricity | ASTM D 2671 | 105 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
