Part Number: FT-600B-V
FT-600B-V Fiber Optic Inspection
Key Features
- 2 inch VSM-360A monitor with multiple functions support
- Brightness contrast; AV video; Single-frame Image Capture
- USB transmission; Zoom and Pan function
- Quick navigation, get image within 3-5 seconds; Two-way focus control
- 95% Image centralization
- 35 types of adapters tips available to inspect different connectors and angle-mounted connectors with limited access space
- Precise resolution (<1 μm), no shadow or vignetting in screen
- Clear image, no interface, no flash
- Reliable output signal, no default under repeated operation
- Various monitors can be chosen with specific display capability
Applications
Specification
- End face inspection for patch cord /bulkhead-mounted equipment/transceiver etc
- End face inspection of assorted connectors PC/APC,MPO/MTRJ etc
- Connector inspection in Fiber network/equipment/kits/assembly
| Magnification/Resolution | 400*/0.75μm(Based on benchmark -8 Inch monitor) |
| Field of View | 0.35mm×0.25mm |
| Tips Connection | Cone contact |
| Focus way /Range | Two-way /<3mm |
| Output Type | PAL or NTSC or USB |
| Light Source/Life time | Coaxial blue LED with 100,000 hrs above |
| Size/Weight （ mm/kg ） | 180*41*36 /0.164 |
| Image Sensor | 1/3 Inch 5V Voltage |
| Temperature | -10~60 ℃ |
| Humidity | 90% Relative humidity Tolerance, no condenses |
