Part Number: FT-BF-MS
Fast Fiber Optic Mechanical Splice for 250um bare fiber
The mechanical splicer is a mechanical splice that provides an inexpensive, quick alternative to mating fibers. Using V-groove technology, this splice maintains physical contact between the fibers.
Features
- Quick splicing time
- Minimal tools
- 250 μm bare fiber capabilities
- Both fiber and coating are secured independently
Applications
- Restoration
- Premise environments
- Fiber-to-the-Subscriber (FTTx) applications
Specifications
| ITEM | Technical Parameters |
|---|---|
| Applicable for | 250um bare fiber |
| Optical fiber diameter | 125μm ( 657A & 657B ) |
| Tight buffer diameter (μm) | 250μm |
| Fiber mode | Single & multi mode |
| Operation time | About 60s(no fiber cut) |
| Aberage Insert loss | ≤0.10dB(1310nm &1550nm) |
| Return loss | ≥40dB |
| Fastening strength of naked fiber | ＞5N |
| Fastening strength of naked fiber holder | ＞10N |
| Using temperature | -45～+80℃ |
| Repeatability(10 times) | △IL≤0.2dB △RL≤5dB |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
