Part Number: FT-CAT5E-FTP-J
Cat5E Shielded(FTP) Keystone Jack/ Network Jack Module
Description
The Category 5e keystone jacks are designed for superior performance that meets or exceeds industry standard TIA/EIA 568-A-5 requirements. The jacks are designed to work in conjunctionwith the wall plates and surface boxes or any standard keystone and angled multimedia wall plateor patch panel.
Specification
- Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5E requirements
- FTP (shielded) keystone jack
- According to UL 1863
- Current rating: 1.5 Amp Max
- Voltage rating: 150 Volts
- Insulation resistance: 500Mega-ohms min
- Contact resistance: 20Milli-ohms max
- DC resistance: 0.1 ohms max
- Data transmission rates up to 250Mbps
- Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min
- Accept 22 to 26 AWG solid wire with a insulation diameter of 0.4 to 0.6 mm
- Covered with metal that provides well anti-EMI performance
- Easy to be terminated low attenuation loss and high return loss
- High reliability and superior performance
Note:
The picture is only for reference, please make the object as the standard. As one kind of the network accessories, a keystone module is a standardized snap-in package for mounting a variety of low-voltage electrical jacks or optical connectors into a keystone wall plate, face plate, surface-mount box, or a patch panel. We F-tone.com can supply a lot of thiskind of products, if you are interested in this Cat5E Shielded(FTP) Keystone Jack/Network Jack Module, or want it in a large quantity, welcome to contact us.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
